NPM-W2 EJM7DE-MB-06M-00
6-2-4
To
12
Every
560
hours
PeriodicPeriodicPeriodicPeriodic
inspection
10
Wipe any excess grease off
●Wipe any excess grease off from X-and Y-axis linear guides or adhered grease out of travel
surfaces.
Grease squeezed out
Y-axis linear guide
●Visually check the installation hole in the linear guide rail from the opposite axis, and wipe off
excess grease, if any.
Installation hole in the
linear-guide rail
Grease squeezed out Excess grease
X-axis linear guide
11
Check the grease sumps
●Wipe off any grease squeezed out.
Grease sump under Y-axis
(left)
Grease sump under Y-axis
(Right)
Grease sump under X-axis
NPM-W2 EJM7DE-MB-06M-00
Select X-axis
Select Y-axis
(Front and rear)
Greasing the XY-axis
linear guide 3
6-2-5
Maintenance
6-2
21
22
23
24
25
26
ENABLING
10 shuttle
Select a table
STOP
12
SERVO
ON
13 14
Detach the
feeder cart
(→P.3-2)
ENABLING
10 shuttle
NPM-W2 EJM7DE-MB-06M-00
6-2-6
To
30
Select a table
Select X-axis
28
29
27
Detach the
feeder cart
(→P.3-2)
Every
560
hours
PeriodicPeriodicPeriodicPeriodic
inspection
STOP
15
16 17
18
19
20
Select Y-axis
OFF
SERVO
