1 1 Confirmation
NPM-W2 EJM7DE-CT-01M-00
S-18
14
Installation
15
Others
16
Reference
-1
Plastic parts listing
-2
Safety data sheet (SDS)
-1
Before installation
-2
Transportation
-3
Installation
-4
Main power connection
-4-1
Checking voltages of the primary power supply
and the machine
-4-2
Connection of the main power supply
-4-3
Adjusting voltages of the primary power supply
and the machine
-5
Connection of air source and power
supply
-6
Peripheral device connection
-6-1
Line configuration
-6-2
Line signal specifications
-6-3
Ethernet cables LWS (line work station)
-6-4
Cable length
-6-5
Settings when connected to LNB
-7
PCB transfer settings
(when connected to non-NPM-W2 equipment)
-8
How to handle the tray feeder
(option)
-9
2D inspection head (option)
-10
Attaching and detaching the safety
cover
(option)
-1
Machine information
-2
Update
-2-1
Updating the machine system
-2-2
Updating the firmware
-3
Option license
-4
Common parameters
1
1 Confirmation
NPM-W2 EJM7DE-SF-01N-00
Safety precautions 1
DANGER
Indicates an imminently hazardous situation that could
result in death, severe bodily injury or major property
damage.
WARNING
Indicates a potentially hazardous situation that could result
in death, severe bodily injury or property damage.
CAUTION
Indicates a potentially hazardous situation that could result
in minor or moderate injury and property damage.
Indicates actions that must not be carried out.
Indicates actions that must be carried out.
Indicates matters to which attention must be paid.
Indicates that you must read the manual.
1-1
1-1-1
The degree of danger or injury resulting from incorrect usage are classified and described as follows.
Precautions that must be observed in order to prevent injury to the user or other persons, and damage to
property are described below.
Precautions that must be observed are classified by the symbols shown and described below.
(The followings are examples of symbols)
