NPM-W 2 EJM7DE-MB-06M-00 6-6 -2 Every 560 hours Periodic Periodic Periodic Periodic inspection OFF SERVO 4 3 5 Detach the feeder cart ( → P.3-2) Remove the nozzle ● Pull it straight out. If pulled out at an angle, the cl…
NPM-W2 EJM7DE-MB-06M-00
6-6-1
Describes how to clean the large reflector.
Tool used: Lint free cloth Time required: 15 minutes
●Leaving the large reflector dirty results in an recognition error.
●For tray feeder specification, move Y-axis of the rear side to the front and work at the front.
Cleaning the large
reflector
(3-nozzle head(option))
Maintenance
6-6
●For the rear side,
1
2
ENABLING
9
SERVO
ON
8
SERVO
ON
7
6
●Y-axis of the front placement
head moves to the front side.
●For feeder specification, Y-
axis of the rear placement
head moves to the rear side,
and for tray feeder
specification, it moves to the
front side.
Wipe the large reflector with a clean lint free
cloth
Large reflector
Attach the
nozzle to the
placement head
●Move the placement head
to the position where you
can work easily
NPM-W2 EJM7DE-MB-06M-00
6-6-2
Every
560
hours
PeriodicPeriodicPeriodicPeriodic
inspection
OFF
SERVO
4
3
5
Detach the
feeder cart
(→P.3-2)
Remove the nozzle
●Pull it straight out. If pulled out at an angle, the clamp claws could
be damaged.
NOTICE
●Work at the front side for front feeder cart specification and rear tray
feeder specification.
●Work at the rear side for rear feeder cart specification.
●Move the head to the position where your workability enhances.
●Hold and pull down the edge of the nozzle reflector.
NPM-W2 EJM7DE-MB-06M-00
Describes how to clean the vacuum pump filter.
Tool used: Allen wrench (4 mm) Time required: 30 minutes
●Be careful not to hit your head during the maintenance work.
7
Cleaning the vacuum
pump filter
Attach the cover
6-7-1
Cover
2
Remove the
feeder cart or
tray feeder of the
rear side
●How to detach
・For a feeder cart
(→P.3-2)
・For a tray feeder
(→P.14-8)
8
Attach the feeder
cart or tray
feeder of the rear
side
●How to attach
・For a feeder cart
(→P.3-2)
・For a tray feeder
(→P.14-8)
●Six screws
(Rear)
Maintenance
6-7
9
Unlock the
machine and
ON
4
1
Turn OFF the
power and lock
the machine
OFF
