NPM-W 2 EJM7DE-MB-06 M-00 6-9 -2 4 6 5 Every 560 hours Periodic Periodic Periodic Periodic inspection Hold the feeder table cover to the back Clean the PCB detection sensors ● Six PCB detection sensors ・ Transparency typ…
NPM-W2 EJM7DE-MB-06M-00
6-9-1
Cleaning the PCB
detection sensors 1
Detach the
feeder cart
(→P.3-2)
Adjust the
conveyor
width of 150mm
(→[Operating
procedure] P.2-5-4)
PCB conveyor
Describes how to clean the PCB detection sensor. Remove the tray feeder before work. (→ P.14-8)
●For better workability
Maintenance
6-9
1
2
OFF
SERVO
3
SERVO
ON
10
9
8
7
Attach the
feeder cart
(→P.3-2)
Tool used: Swabs Time required: 10 minutes for single conveyor 15 minutes for dual conveyor
Return the
feeder table
cover back
NPM-W2 EJM7DE-MB-06M-00
6-9-2
4
6
5
Every
560
hours
PeriodicPeriodicPeriodicPeriodic
inspection
Hold the feeder
table cover to
the back
Clean the PCB
detection sensors
●Six PCB detection sensors
・Transparency type: Four sets
(a pair of the light-emitting side
and the light-receiving side)
・Reflection type: Two sets
PCB detection sensor
(Reflection type)
PCB detection sensor
(Transparency type)
PCB conveyor
■For single conveyor
●Five PCB detection sensors on each
lane
・Transparency type: Four sets
(a pair of the light-emitting side
and the light-receiving side)
・Reflection type: Two sets
■For dual conveyor
●Use swabs.
●Neither lean against the
feeder table cover nor place
anything on it.
NPM-W2 EJM7DE-MB-06M-00
Tool used: Swabs, Allen wrench (3 mm) Time required: 5 minutes
Extension conveyor (option)
Cleaning the PCB
detection sensors 2
Maintenance
6-9
Detach the
feeder cart
(→P.3-2)
Adjust the
conveyor
width of 150mm
(→[Operating
procedure] P.2-5-4)
●For better workability
1
2
OFF
SERVO
3
SERVO
ON
10
9
8
7
Attach the
feeder cart
(→P.3-2)
Return the
feeder table
cover back
6-9-3
