NPM-W2 EJM7DE-MB-06M-00
This section explains the procedure for a single tray feeder. Follow the same procedure for a twin tray feeder.
Tool used: Grease gun Time required: 20 minutes for a single tray feeder, 40 minutes for a twin tray
feeder
Greasing to the tray
feeder
(option) 1
6-13-1
Maintenance
6-13
OFF
SERVO
OFF
SERVO
SERVO
ON
7
8
1
2
3
9
11
10
For a twin tray
feeder, select a
table
or
ENABLING
(The tray feeder drawer
moves to the maintenance
position.)
ENABLING
Open the magazine
cover and remove the
upper magazine
(→[Operating procedure]
P.2-4-2)
Push the X-axis
inward
NPM-W2 EJM7DE-MB-06M-00
To
12
6-13-2
4
5
6
Apply grease via grease nipples to the
vertical-axis ball screw and the linear guide for
the lifter
Ball screw
Grease nipple
●Apply grease via grease nipples
with a grease gun.
Give two pumps for each
(Approx. 1.8 cm
3
)
●Grease: LCG100
Every
560
hours
PeriodicPeriodicPeriodicPeriodic
inspection
NPM-W2 EJM7DE-MB-06M-00
Greasing to the tray
feeder
(option) 2
6-13-3
12
Apply grease to each point of the tray feeder drawer
●For a twin tray, A and B
Linear guide
(right and left)
Inside of cam block (left)
Front
●Greasing points
・Linear guide rails (right and left)
・Inside of cam blocks (right and left)
●Grease: LCG100
Inside of cam block (right)
18
ENABLING
19
Have it run for about a
minute, and then
Maintenance
6-13
SERVO
ON
17
