NPM-W2 EJM7DE-MB-06M-00
Greasing to the tray
feeder
(option) 2
6-13-3
12
Apply grease to each point of the tray feeder drawer
●For a twin tray, A and B
Linear guide
(right and left)
Inside of cam block (left)
Front
●Greasing points
・Linear guide rails (right and left)
・Inside of cam blocks (right and left)
●Grease: LCG100
Inside of cam block (right)
18
ENABLING
19
Have it run for about a
minute, and then
Maintenance
6-13
SERVO
ON
17
NPM-W2 EJM7DE-MB-06M-00
14
15
16
Place the
magazines back in
place and close
the magazine
cover
(→[Operating procedure]
P.2-4-2)
Drawer-axis
13
Pull drawer-axis of the tray feeder upper
surface toward you
●As the drawer is around the
magazine door, pull it toward you
as below.
Drawer
-axis
Apply grease to each part of the tray
feeder drawer
●Greasing points
・Linear guide (right and left)
・Inside of cam plates (right and left)
●Grease: LCG100
Place the drawer
back as its
original position
Drawer-axis
●For a twin tray, A and B
Linear guide
Drawer-axis
Cam plate
Drawer-axis
Greasing area
6-13-4
Front
Every
560
hours
PeriodicPeriodicPeriodicPeriodic
inspection
NPM-W2 EJM7DE-MB-06M-00
Describes how to clean the tray feeder magazine slot.
Tool used: Lint free cloth Time required: 10 minutes
2
1
Cleaning the slot
(tray feeder magazine(option))
Check the slots
Clean the slots
6-14
Slot
Slot
●Wipe it off with a soft dry
cloth.
●Visually check
whether the slots are
free from chipping,
racks or breaks.
Lint free cloth
Maintenance
6-14
