NPM-W 2 EJM7DE-MB-06M-00 Describes how to clean the tray feeder magazine slot. Tool used: Lint free cloth Time required: 10 minutes 2 1 Cleaning the slot (tray feeder magazine(optio n)) Check the slots Clean the slots 6-…
NPM-W2 EJM7DE-MB-06M-00
14
15
16
Place the
magazines back in
place and close
the magazine
cover
(→[Operating procedure]
P.2-4-2)
Drawer-axis
13
Pull drawer-axis of the tray feeder upper
surface toward you
●As the drawer is around the
magazine door, pull it toward you
as below.
Drawer
-axis
Apply grease to each part of the tray
feeder drawer
●Greasing points
・Linear guide (right and left)
・Inside of cam plates (right and left)
●Grease: LCG100
Place the drawer
back as its
original position
Drawer-axis
●For a twin tray, A and B
Linear guide
Drawer-axis
Cam plate
Drawer-axis
Greasing area
6-13-4
Front
Every
560
hours
PeriodicPeriodicPeriodicPeriodic
inspection
NPM-W2 EJM7DE-MB-06M-00
Describes how to clean the tray feeder magazine slot.
Tool used: Lint free cloth Time required: 10 minutes
2
1
Cleaning the slot
(tray feeder magazine(option))
Check the slots
Clean the slots
6-14
Slot
Slot
●Wipe it off with a soft dry
cloth.
●Visually check
whether the slots are
free from chipping,
racks or breaks.
Lint free cloth
Maintenance
6-14
NPM-W2 EJM7DE-MB-06M-00
Cleaning the safety
cover
Describes how to clean the safety cover.
Tool used: Lint free cloth, neutral detergent Time required: 5 minutes
●Rather than cleaning the safety cover once a month, clean it as needed.
1
Wipe the cover
●Because the surface of the safety cover is
susceptible to damage, be careful neither to
scratch nor generate friction.
●Never use an undiluted neutral detergent such as alcohol, thinner or a cleaner (solvent).
(It causes cracks or significant reductions in anti-static effect.)
NOTICE
6-15
●If it is badly stained, wipe off with a soft cloth
immersed in a neutral detergent diluted 200
times with water.
●Be sure to use a damp cloth because a dried
cloth can scratch more easily even if it is soft.
Maintenance
6-15
Every
560
hours
PeriodicPeriodicPeriodicPeriodic
inspection
