NPM-W2 EJM7DE-MB-06M-00
6-19-2
To
8
●Remove the syringe part before work. (→P.4-2-5)
●Wipe away old grease off
the ball screw and linear
guide using a clean lint
free cloth.
Wipe away old
grease
Apply grease from
the grease nipple of
the ball screw
4
1
OFF
SERVO
3
7
6
2
5
ENABLING
Detach the
feeder cart
(→P.3-2)
Detach the feeder table cover
(→P.3-3)
Grease nipple
●Apply grease each axis of
pos.1 and pos.2.
●Amount: 0.3 cm
3
each.
●Grease: LCG100
Every
560
hours
PeriodicPeriodicPeriodicPeriodic
inspection
●If it is difficult to perform the
work, remove the feeder table
cover.
●Neither lean against the feeder
table cover nor place anything
on it.
NPM-W2 EJM7DE-MB-06M-00
6-19-3
Maintenance
6-19
Stop continuous
operation
21
9
18
●If any, wipe it off.
Check excess
grease
STOP
Greasing the
dispensing head (option) 2
8
Apply grease from the grease nipple of the
linear guide
Grease nipple
●Apply grease each axis of
pos.1 and pos.2.
●Amount: 0.3 cm
3
each.
●Grease: LCG100
OFF
SERVO
19
20
1617
ENABLING
●To spread the applied
grease, run a continuous
operation f at least five
times
Choose Z2-axis
Return the
feeder table
cover back
NPM-W2 EJM7DE-MB-06M-00
6-19-4
ENABLING
●To spread the applied
grease, run a continuous
operation f at least five
times
Stop continuous
operation
13
15
14
12
Attach the
feeder cart
(→ P.3-2)
Choose Z1-axis
Every
560
hours
PeriodicPeriodicPeriodicPeriodic
inspection
STOP
SERVO
ON
1110
SERVO
ON
23
22
