NPM-W2 EJM7DE-MB-06M-00
6-19-3
Maintenance
6-19
Stop continuous
operation
21
9
18
●If any, wipe it off.
Check excess
grease
STOP
Greasing the
dispensing head (option) 2
8
Apply grease from the grease nipple of the
linear guide
Grease nipple
●Apply grease each axis of
pos.1 and pos.2.
●Amount: 0.3 cm
3
each.
●Grease: LCG100
OFF
SERVO
19
20
1617
ENABLING
●To spread the applied
grease, run a continuous
operation f at least five
times
Choose Z2-axis
Return the
feeder table
cover back
NPM-W2 EJM7DE-MB-06M-00
6-19-4
ENABLING
●To spread the applied
grease, run a continuous
operation f at least five
times
Stop continuous
operation
13
15
14
12
Attach the
feeder cart
(→ P.3-2)
Choose Z1-axis
Every
560
hours
PeriodicPeriodicPeriodicPeriodic
inspection
STOP
SERVO
ON
1110
SERVO
ON
23
22
NPM-W2 EJM7DE-MB-06M-00
6-20-1
Greasing the dummy
dispensing unit
(dispensing head(option))
Maintenance
6-20
Describes how to grease the linear guide and rack & pinion of the dummy dispensing unit.
Tool used: Lint free cloth, gloves Time required: 15 minutes (per location)
●Wipe any excess grease
off
Check excess
grease
or
OFF
SERVO
3
1
2
ENABLING
●The head moves to the
exchange position.
8
9
10
Attach the
dummy
dispensing unit
1
2
①Tilt the attachment lever to
the left
②Attach the dummy
dispensing unit
SERVO
ON
11
