NPM-W 2 EJM7DE-MB-07 M-00 7-1 -13
NPM-W2 EJM7DE-MB-07M-00
7-1-12
1
Clean the refresh jigs
3
Wipe off contamination on
the shaft
11
Check the sliding
of the nozzle
holder.
2
Clean the shaft
●Insert the cleaning tool to
the shaft and rotate it two
or three times in a nozzle
rotation direction.
●If the paper becomes dirty,
replace it.
●Hold the shaft by hand,
and push up and
horizontally rotate the
nozzle holder shaft
cleaning tool.
4
Clean the shaft
●Insert the cleaning tool to
the shaft and rotate it two
or three times in a nozzle
rotation direction.
●If the paper becomes dirty,
replace it.
10
7 9
●Perform until the jig can
be inserted smoothly.
●Do not insert it forcefully.
The jig may get stuck.
●How to attach the nozzle
holder (→P.7-1
-8)
Nozzle holder
refresh jigs
Alcohol-dampened lint
free cloth
Nozzle holder shaft
cleaning tool
Alcohol-dampened cotton
swab
Perform steps
to
NOTICE
Every
1000
hours
PeriodicPeriodicPeriodic
inspection
●If it does not slide smoothly,
repeat steps from to .
1
10
NPM-W2 EJM7DE-MB-07M-00
7-1-13
8 Periodic inspection
Every-3000-hours
