NPM-W2 EJM7DE-SF-01N-00
CAUTION
1-1-8
Observe the precautions
described in the Product’s
[Safety Data Sheet]
(Cause of injury or damage by chemical
substances)
●Safety Data Sheets can be found in the
[Maintenance manual].
Wear a cloth hat or helmet
and protective goggles
during maintenance work
(Risk of injury)
●Motor or control boxes.
Handle the feeder carefully
when carrying it
(Risk of injury/backache due to dropping)
●Handle properly in accordance with the
manual.
Do not apply any impact to
motors or other electrical
equipment
(Risk of electric shock, cause of electrical
leakage)
●Motor or control boxes.
Do not climb on equipment,
peripheral devices and
moving parts
(Cause of damage by load or injury by
failing or being stuck in the equipment)
●Covers, the feeder cart and inspection
box.
Be sure to observe the following
Do not put any
objects around
emergency stop
switches
(Risk of an accident due to being
unable to press the switch to stop the
machine in case of emergency)
Confirmation
To prevent
injury or
electric
shock…
NPM-W2 EJM7DE-SF-01N-00
C
Warning labels 1
Danger labels
1-2-1
Follow the instructions on labels on the locations below.
If it has come off, place an order with us for it, referring to its label No. in the Parts List; then, put the new one
on the proper location.
1-2
■NPM-W2 main unit
Front side
On the right edge of
the feeder cover
On the right edge of
the feeder cover
(*1) Labels are affixed
for feeder chart
specification
PD0101M1
(*1)
Front side Rear side
NPM-W2 EJM7DE-SF-01N-00
1-2-2
Confirmation
■Twin tray feeder
Operator side
■Single tray feeder
Operator side
PD0101M1
PD0101M1
