NPM-W 2 EJM7DE-SF-01N-0 0 1-2 -2 Confirmation ■ T win tray feeder Operator side ■ Single tray feeder Operator side PD0101M1 PD0101M1
NPM-W2 EJM7DE-SF-01N-00
C
Warning labels 1
Danger labels
1-2-1
Follow the instructions on labels on the locations below.
If it has come off, place an order with us for it, referring to its label No. in the Parts List; then, put the new one
on the proper location.
1-2
■NPM-W2 main unit
Front side
On the right edge of
the feeder cover
On the right edge of
the feeder cover
(*1) Labels are affixed
for feeder chart
specification
PD0101M1
(*1)
Front side Rear side
NPM-W2 EJM7DE-SF-01N-00
1-2-2
Confirmation
■Twin tray feeder
Operator side
■Single tray feeder
Operator side
PD0101M1
PD0101M1
NPM-W2 EJM7DE-SF-01N-00
C
Warning labels 2
1-2
Danger labels
Front side
Rear side
1-2-3
●It is attached on the bottom of the base
inside the machine.
