NPM-W 2 EJM7DE-MB-12M-00 12-9 -3
NPM-W2 EJM7DE-MB-12M-00
12-9-2
3
4
OFF
SERVO
2
●Y-axis of the front placement
head moves to the front side.
●For feeder cart specification, Y-
axis of the rear placement head
moves to the rear side, and for
tray feeder specification, it moves
to the front side.
5
●Work at the front side for front feeder cart specification
and rear tray feeder specification.
●Work at the rear side for rear feeder cart specification.
12
11
SERVO
ON
10
Detach the feeder
cart
(→P.3-2)
Attach the feeder
cart (→P.3-2)
Consumable parts
replacement
NPM-W2 EJM7DE-MB-12M-00
12-9-3
13 Calibration
