NPM-W 2 EJM7DE-MB-13M-00 13-1-1 -2 Calibration
NPM-W2 EJM7DE-MB-13M-00
Over-
view
Maintenance
13-1-1
Calibration
performance
To maximize the machine’s capability, you need to adjust parameters installed on the machine to the site
environment. This task is called calibration.
Chapter 12 describes the calibration method.
■Do this task if any of the following events should occur;
●Relocation of the machine.
●Replacement of unit(s).
●Floor level change.
■Observe the following conditions as you perform the task.
●Turn ON the main power switch of the machine at least one hour before you start the task.
●Do not warm up the machine before you start the task.
●Wait for over an hour to start the task, immediately after the machine stops production or warm-up
operation.
13-1-1-1
NPM-W2 EJM7DE-MB-13M-00
13-1-1-2
Calibration
NPM-W2 EJM7DE-MB-13M-00
STEP Item Action
Changes in machine condition
and calibrations to be performed
Time
required
[Min]
Relocation,
change in
floor level
Replacement
of head
1)
STEP1
Head camera XY origin
Camera angle
5
XY origin camera scale
5
Plane correction XY Plane correction XY
30
STEP2
Plane correction Z
Height measurement
5)
5
Plane correction Z
5)
20
Dummy dispensing
height
()()
5
Width adjustment Width adjustment
10
Placement
position/Conveyor
Height measurement
5
PCB stop position
5
Height sensor
(option)
Height measurement
()()
10
Placement load
(3-nozzle head)
Placement load
measurement F1 and F2
15
STEP3
Multi-recognition camera
Head
origin
5
Camera offset
10
Jig station
(per head)
Scan position
4) 5)
4)
40
2)
Nozzle changer height
4) 5)
Head camera lighting
Multi-recognition camera
lighting
4) 5)
Head offset
4) 5)
4)
Dispensing head (option)
Head
origin
()()
5
Head offset
()()
5
White balance (option: 2D
inspection head)
White balance adjustment
5
Get target values of
calibrated PCB
5
Camera offset (option:2D
inspection head)
-
()
5
Image quality correction
(option: 2D inspection head)
-
()
30
Inspection plane correction
(option: 2D inspection head)
-
()
5
STEP4
Pickup position Pickup position
10
Tray (option)
Pickup height
()
10
Pickup position 1
()
Pickup position 2
()
Transfer Height measurement
()()
10
■Calibration item and action
Over-
view
Calibration item and
action
13-1-2-1
Maintenance
13-1-2
