NPM-W 2 EJM7DE-MB-13 M-00 Menu Jig Multi-reco gnition camera Jig station Light weight 16-,12-nozzle head :153AS nozzle 8-nozzle head :184-nozzle 3-nozzle head :1003-nozzle Dispensing head (option) Camera offset (option…
NPM-W2 EJM7DE-MB-13M-00
STEP Item Action
Changes in machine condition
and calibrations to be performed
Time
required
[Min]
Relocation,
change in
floor level
Replacement
of head
1)
Accuracy
verification
Placement accuracy, Reflection
4) 5)
4)
30
Placement accuracy, Verification
4) 5)
4)
30
2D inspection head, Reflection (option)
()
15
2Dinspection head, Verification (option)
()
15
Dispensing head accuracy, Reflection (option)
()()
15
Dispensing head accuracy, Verification (option)
()()
15
13-1-2-2
:Perform ():Perform only on a machine with any optional unit
*1) Perform calibration only on the table of which the unit has been replaced.
*2) Time required for the light weight 16-nozzle head. 12-, 8-, and 3-nozzle heads require 35, 30, and 20
minutes, respectively.
*3) Calibration is also required when APC option is purchased and a head is installed.
*4) It is not carried out for the dispensing head.
*5) It is not carried out for the 2D inspection head.
Calibration
NPM-W2 EJM7DE-MB-13M-00
Menu Jig
Multi-recognition
camera
Jig station
Light weight 16-,12-nozzle
head
:153AS nozzle
8-nozzle head
:184-nozzle
3-nozzle head
:1003-nozzle
Dispensing head
(option)
Camera offset
(option: 2D inspection
head)
White balance
(option: 2D inspection
head)
Image quality
correction (option: 2D
inspection head)
Inspection place
correction
(option: 2D inspection
head)
Over-
view
Jigs used for
calibration
■STEP 3
Jig station
(N610087861AA)
Light luminosity jig
(N610114318AA)
Two jig
components
(N610102559AA)
For light weight 16-,
12-, 8-Nozzle head
(N610071657AA)
For 3-nozzle head
(N610003301AA)
Multi-recognition camera jig
Menu Jig
Plane correction Z
Placement
position/Conveyor
Light weight 16-,12-nozzle
head
:230CS
8-nozzle head
:230C
3-nozzle head
:1002 nozzle
Width adjustment
Placement load
Height sensor
(option)
Menu Jig
Head camera XY origin
Plane correction XY
■STEP 1
*1)
Plane correction jig
(N210147296AB)
Placement load
measurement jig
(N610084605AA)
Load cell meter
(N610093887AC)
■STEP 2
13-1-3-1
NOTICE
230CS and 230C nozzles are not included with the
calibration jig (option). Please prepare them on your
own.
1003 nozzle
(KXFX037UA00)
Maintenance
13-1-3
Height sensor jig
(N610122649AA)
*1)
Plane correction jig
(N210147296AB)
User master board
(gray)
(N610106576AA)
1) It is common to for NPM-W and AM100. The
plane correction jig for NPM-D series and NPM-
TT cannot be used. For other jigs, they are
common to the ones for NPM series.
NPM-W2 EJM7DE-MB-13M-00
13-1-3-2
Menu Jig
Pickup position
Light weight 16-,12-nozzle
head
: 230CS nozzle
8-nozzle head
: 230C nozzle
3-nozzle head
: 1002 nozzle
Tray
8-nozzle head
: 230C nozzle
3-nozzle head
: 1002 nozzle
Transfer
3-nozzle head
: 1003 nozzle
■STEP 4
Pickup position height
teaching jig
(N610003318AA)
