NPM-W 2 EJM7DE-MB-13M-00 13-1-4 -2 Calibration
NPM-W2 EJM7DE-MB-13M-00
Over-
view
Explanation of screen
A
B
Calibration process
A
B
CD
Items of each calibration
process
C
Actions to execute and actions
required for preparation
D
Parameter
Indicates the parameters set up by
calibration. Pressing this button displays
the parameters currently registered.
13-1-4-1
Maintenance
13-1-4
NPM-W2 EJM7DE-MB-13M-00
13-1-4-2
Calibration
NPM-W2 EJM7DE-MB-13M-00
Choose a table
●Choose the table to calibrate.
2
+
1
Head camera XY origin
Explains the method for calibrating the head camera’s XY origin, taking for an example, the 12-nozzle head;
however, the same method can also be applied to the light weight 16-, 8-, and 3-nozzle heads.
You must operate the machine under the pre-operation status in the following environmental conditions;
temperature: 10 to 35 ℃ and humidity: 25 to 75 % RH.
(The camera angle is calibrated)
Confirm that it has been
successfully completed
+
(The XY origin camera scale is
calibrated)
12
3
13-2-1
3
