NPM-W2 EJM7DE-MB-13M-00
12
Confirm that it has been
successfully completed
●If it has been successfully completed,
the display of each nozzle position is
changed from '-' to 'OK'.
(The head moves to the work position)
12
+
13-4-3
13
Prepare for plane correction Z
14
Open the safety cover
15
16
Check the nozzle installation
positions
●Nozzle used
Head
type
Nozzle
position
Nozzle
type
16 No. 5
230CS
12 No. 4
8 No. 3 230C
3No. 21002
Maintenance
13-4
Servo switch OFF
Head / Plane
calibration Z 2
Placement head 2
NPM-W2 EJM7DE-MB-13M-00
21
Confirm that it has been
successfully completed, and
choose the other table for
plane correction Z and then
repeat steps from to
21
19
2
20
13-4-4
17
18
Servo switch ON
Close the safety cover
+
Confirm the message
■To cancel
(The screen remains as it is
in )
13
19
Calibration
20
Confirm the message
20
(Calibration for the plane correction Z
starts)
+
NPM-W2 EJM7DE-MB-13M-00
13-4-5
22
Confirm that it has been
successfully completed
23
Confirm the message
(The plane correction Z data is saved)
■When you do not save the data
■To cancel
(The screen remains as it is in )
22
23
Maintenance
13-4
22
Placement head 3
Head / Plane
calibration Z 3
(The head moves to the retraction position)
