NPM-W 2 EJM7DE-MB-13M-00 13-7 -6 Calibration
NPM-W2 EJM7DE-MB-13M-00
13-7-5
Maintenance
13-7
Height sensor (option) 3
+
■When you do not remove the nozzle
(The head remains as it is in )
Servo switch ON
+
■When you do not remove the jig PCB
(The screen remains as it is in )
Remove the height sensor jig
Close the safety cover
Open the safety cover
(Confirm whether any PCB remains on
the transfer rail)
Servo switch OFF
Servo switch ON
26
25
32
29
30
31
28
27
19
26
32
19
(The head moves to the retraction position)
NPM-W2 EJM7DE-MB-13M-00
13-7-6
Calibration
NPM-W2 EJM7DE-MB-13M-00
Place-
ment
load
Placement load 1
The operation procedure is applicable only to the 3-nozzle head.
13-8-1-1
Maintenance
13-8-1
Choose a table
●Choose a table to calibrate.
2 13
+
Servo switch OFF
Open the safety cover
Prepare to remove a jig
1
2
3
6
5
4
(The width is adjusted)
(The head moves to the retraction position)
