NPM-W2 EJM7DE-MB-13M-00
13-8-2-4
Confirm the display value
(The value is displayed, and the lamp
flashes)
(The input value 1 is set)
(Teaching is complete and then the lamp
changes from flashing to illumination)
Confirm that the display value
becomes stable
(The display value 1 is set)
■If the screen display differs
(The display flashes)
Choose it with
8
9810
9
11
1112
10
11
7
8
9
12
Put a 100g weight on the load
cell
Calibration
NPM-W2 EJM7DE-MB-13M-00
Place-
ment
load
How to use placement load
measurement jig
(option) 3
13-8-2-5
Maintenance
13-8-2
(The value is displayed, and the lamp
flashes)
(Teaching is complete and then the lamp
changes from flashing to illumination)
Confirm that the display value
becomes stable
(The input value 2 is set)
Confirm the display value
(The display value 2 is set)
■If the screen display differs
(The display flashes)
Choose it with
14
151416
15
17
1718
13
14
15
16
17
18
Calibration method 2
Put a 1kg weight on the load cell
NPM-W2 EJM7DE-MB-13M-00
13-8-2-6
19
19
20
21
192021
Confirm the decimal point position
(The decimal point position is set)
■To change
(The screen display flashes)
Hold down
for at least a second
(Returns to the operation level)
Choose it with
Calibration
