NPM-W 2 EJM7DE-MB-13M-00 Split r ecognition (option) 2 13-1 1 -3 Maintenance 13-1 1 14 Confirm the measurement result OK: When the result is successfully completed NG: If measurement results in error, (perform from the s…
NPM-W2 EJM7DE-MB-13M-00
Open the safety cover
9
8
13
10
11
Place the multi-recognition
camera jig to the
predetermined head
13-11-2
Confirm the message
■When you do not retract
(The screen remains as it is in )
1
6
(The head moves to the retraction
position of the feeder cart side
6
+
12
Close the safety cover
13
multi-recognition
camera jig
(for 3-nozzle
head)
Confirm the message and
prepare for installing the multi-
recognition camera jig
■When you do not install the multi-
recognition camera jig
(The screen remains as it is in )
1
7
(The head performs recognition operation)
+
Confirm the message
Calibration
Servo switch OFF
Servo switch ON
NPM-W2 EJM7DE-MB-13M-00
Split recognition (option) 2
13-11-3
Maintenance
13-11
14
Confirm the measurement result
OK: When the result is successfully
completed
NG: If measurement results in error,
(perform from the step )
－ :Unmeasured
5
15
Pressing other menu screen
appears confirmation message
of data save
(The data obtained by calibration is
cleared
(The data obtained by calibration is
saved)
■When you do not save
■To cancel
(The screen remains as it is in )
14
15
+
16
Confirm the message
■When you do not retract
(The screen remains as it is in )
14
16
Open the safety cover
18
17
Servo switch OFF
14
NPM-W2 EJM7DE-MB-13M-00
13-11-4
22
21
19
23
Remove the multi-recognition
camera jig
The selected menu (other
menu) is displayed
20
20
Confirm the message
■When you do not remove the multi-
recognition camera jig
(The screen remains as it is in )
14
Calibration
Close the safety cover
Servo switch ON
