NPM-W 2 EJM7DE-MB-13M-00 Open the safety cover 6 5 4 Prepare to install the nozzle 7 9 8 Close the safety cover 13-18 -2 Install nozzles ● Nozz le used Head type Nozzle position Nozzle type 16 No. 5 230CS 12 No. 4 8 No. …
NPM-W2 EJM7DE-MB-13M-00
Pickup position 1
Explains the operation procedure, taking for an example, the 12-nozzle head; however, the same
procedure can also be applied to the light weight 16-, 8-, and 3-nozzle heads.
Remove the feeders from the slots indicated in the following conditions beforehand;
●For a feeder cart: No. 1, 2, 3, 14, 15, 16, 28, 29, 30
●For 13-slot feeder: No. 18, 19, 20, 23, 24, 25, 28, 29, 30
2
Choose a table
●Choose the table for calibration.
+
2
3
1
13-18-1
3
1
Maintenance
13-18
(The head moves to the working
position.)
NPM-W2 EJM7DE-MB-13M-00
Open the safety cover
6
5
4
Prepare to install the nozzle
7
9
8
Close the safety cover
13-18-2
Install nozzles
●Nozzle used
Head
type
Nozzle
position
Nozzle
type
16 No. 5
230CS
12 No. 4
8 No. 3 230C
3No. 21002
10
■To cancel
(The screen remains as it is
in )
3
Confirm the message
10
+
Servo switch ON
Servo switch OFF
Calibration
(The head moves to the working
position.)
NPM-W2 EJM7DE-MB-13M-00
13-18-3
Install the pickup position
height teaching jig
(Calibration is carried out)
■To cancel
(The screen remains as it is in )
3
Confirm the message
Pickup position height
teaching jig
+
Maintenance
13-18
Pickup position 2
12
13
11
13
+
11
Set the jig to the No. 19 slot located on the right side.
Set the jig to the No. 2 slot located on the left side of
the table selected in step .
1
No. 19 slotNo. 2 slot
■For a 13-slot feeder
■For a feeder cart
