NPM-W 2 EJM7DE-MB-13M-00 Install the pickup position height teaching jig 13-18 -5 Confirm that it has been successfully completed ● Repeat steps from to from the other table. 1 ■ To cancel (The screen remains as it is in…

100%1 / 572
NPM-W2 EJM7DE-MB-13M-00
Install the pickup position
height teaching jig
13-18-4
(Calibration is carried out)
■To cancel
(The screen remains as it is
in )
3
Confirm the message
+
Calibration
14
15
15
Place the jig to the No. 15 slot located at the center of
the table selected in step .
Set the jig to the No. 24 slot located on the right side.
1
■For a 13-slot feeder
■For a feeder cart
No. 24 slotNo. 15 slot
NPM-W2 EJM7DE-MB-13M-00
Install the pickup position
height teaching jig
13-18-5
Confirm that it has been
successfully completed
●Repeat steps from to
from the other table.
1
■To cancel
(The screen remains as it is
in )
3
Confirm the message
+
Maintenance
13-18
Pickup position 3
16
18
19
17
17
1819
17
●Set the jig to the No. 29 slot located
on the right side of the table selected
in step .
(Set the jig to the same slot for both
the feeder cart and the 13-slot feeder)
1
No. 29 slot
NPM-W2 EJM7DE-MB-13M-00
13-18-6
Confirm the message
(The calibration data is saved)
■When you do not save the data
■To cancel
(The screen remains as it is
in )
Remove the installed pickup
position height teaching jig
Remove nozzles
Open the safety cover
Close the safety cover
Prepare to remove nozzles
Servo switch ON
Servo switch OFF
Calibration
21
20
24
25
23
27
26
22
18
21
