NPM-W 2 EJM7DE-MB-13M-00 13-19 -6 Calibration
NPM-W2 EJM7DE-MB-13M-00
13-19-5
Tray 3
Open the safety cover
Remove the nozzles from the
nozzle changer No.11
Close the safety cover
Maintenance
13-19
19
20
18
22
21
Servo switch OFF
Servo switch ON
NPM-W2 EJM7DE-MB-13M-00
13-19-6
Calibration
NPM-W2 EJM7DE-MB-13M-00
Transfer 1
13-20-1
Maintenance
13-20
1
2
4
This operation is calibration in the transfer unit.
Information on the relative position for the head height and the transfer stage forming flax is required to
transfer flax to the component. Performing this calibration allows measuring and registering transfer
position offset to calculate the above relative position. If the transfer unit is removed/installed, the transfer
position offset may be varied. Therefore, perform this calibration and register transfer position offset.
●If the transfer unit is not installed, this operation is not available.
●This is applied for the 3-nozzle head.
1
2
3
3
Choose a table
●Choose the table for calibration.
■To cancel
(The screen remains as it is
in )
1
Confirm the message
+
(The head moves to the working
position.)
Prepare to install the nozzle
