NPM-W 2 EJM7DE-MB-13M-00 13-20 -4 Calibration 17 19 20 22 21 23 23 18 ■ To cancel (The screen remains as it is in ) 11 Confirm the message + Open the safety cover Remove nozzles Close the safety cover Prepare to remove n…
NPM-W2 EJM7DE-MB-13M-00
13-20-3
Transfer 2
Maintenance
13-20
Confirm that it has been
successfully completed
12
11
14
15
12
To check parameters
(Transitions to the screen of )
13
14
13
Check transfer position
offset
13
15
(Transitions to the screen of )
11
16
16
11
■To cancel
(The screen remains as it is
in )
11
Confirm the message
+
(The head moves to the working
position.)
NPM-W2 EJM7DE-MB-13M-00
13-20-4
Calibration
17
19
20
22
21
23
23
18
■To cancel
(The screen remains as it is
in )
11
Confirm the message
+
Open the safety cover
Remove nozzles
Close the safety cover
Prepare to remove nozzles
Servo switch ON
Servo switch OFF
NPM-W2 EJM7DE-MB-13M-00
Maintenance
13-21-1
13-21-1-1
Overview 1
(placement head / dispensing head)
Accuracy
verifica-
tion
Accuracy verification
■MCDATA type
MCDATA (production program) is exclusively used for accuracy verifications.
There are the following two types of MCDATA used for placement accuracy verifications.
Offset Refection MCDATA
*The one with “Ost” included in its
data name
The front and rear heads execute placement independently from each
other, and the placement locations are measured. This is used to
reflect the each-position-angle offsets, obtained from measurement
results, separately as the front or rear head use.
Accuracy Verification MCDATA
*The one with “Ins” included in its
data name
The front and rear heads execute alternate placement that is an
operation close to normal placement, and this is used in measuring the
placement locations.
MCDATA filename
W2 - L16 -L16 - F – F _ 05JIG - Ost ＊＊＊
■Reflection of verification data
Make sure not to reflect the each-position-angle offsets, obtained after measurement, in “Accuracy verification
MCDATA” because the MCDATA is used for verification purpose.
When using MCDATA for component placement, the following message appears before the start of production.
Select [Yes] / [No] according to the type of the data you use.
●When accuracy is verified using ‘Offset Refection
MCDATA’ (-Ost)
●When accuracy is verified using ‘Accuracy Verification
MCDATA’ (-Ins)
+
+
①
Machine name W2 (NPM-W2)
②
Head
configuration
L16: light weight 16-nozzle / M12: 12-nozzle / M08: 8-nozzle / M03: 3-nozzle / NON:
without heads / I18: inspection head 18μm / I09: inspection head 9μm / D02:
dispensing head / ALL: This is used only when inspection head is verified, and the
type of the diagonal head is not considered
③
Supply unit
configuration
F: feeder / TT: twin tray feeder / FT: 13-slot feeder + Tray feeder / N: when head
configuration is either no head or dispensing head
④
Component
05JIG: 1005 jig component / 02R: 0402R / 015R: 03015R / BGA: BGA jig
component
⑤
Mode
Ost: for offset reflection use / Ins: for accuracy verification use / InsH: 0.025 mm-
ready accuracy verification use
⑥
Available nozzle
①② ③ ④ ⑤ ⑥
Explains considerations for accuracy verification.
About accuracy verification of the machine with a combination of the placement head and the inspection
head, see P.13-21-1
-7.
