Brief description of process
This section describes the procedures for measuring the inspection head accuracy and updating the
inspection camera offset by using the measured result. The plane correction jig is used for
measurement.
●Because the plane correction jig is inserted and taken out from the upstream process, adjust the
width of the upstream transfer conveyor to that of the plane correction jig.
The dedicated MCDATA (production
program) is used for inspection head
accuracy verification and registering the
inspection camera offset. When the
inspection camera offset is reflected,
machine parameters in the machine will
be rewritten.
●You are recommended to save the
current data beforehand just in case.
(→[Operating procedure] P.2-3-4)
MCDATA (production program)
●There are two inspection head types: 18 μm and 9 μm.
●If the inspection head is attached, the supply unit is only on the rear side.
Front: Inspection BOX(I)
Rear: Tape feeder (F), single tray feeder (FT)
*1)
or twin tray feeder (TT)
● In the head pattern, for example, 9I-8F shows the front: 9 μm inspection head, the rear: 8- nozzle head,
and the tape feeder supply section.
Likewise, 18I-3FT shows the front: 18 μm inspection head, the rear: 3- nozzle head, and the single tray
feeder supply section
*1)
.
Placement head accuracy
verification
Head pattern
9I-LW16F 18I-LW16F
9I-12F 18I-12F
9I-8F 18I-8F
9I-3F 18I-3F
9I-8FT(TT) 18I-8FT(TT)
9I-3FT(TT) 18I-3FT(TT)
9I-8FT(TT) 18I-8FT(TT)
9I-3FT(TT) 18I-3FT(TT)
■The table below is the major configuration of heads and supply sections
1.Production
preparation
・Saving calibration DATA (DVD-ROM) to an
SD card
・Setting up the plane correction jig
・Setting production operation
■Working process
3.Confirmation of
accuracy
verification result
・Selection of MCDATA (Production program)
・Measurement
・Checking of measurement results
2.Check and
reflection of
measurement
(offset registration)
・Selection of MCDATA (Production program)
・Measurement
・Checking and reflection of placement results
LW16: Light weight 16-nozzle head
F: Tape feeder specifications
FT: Single tray feeder specifications
*1)
TT: Twin tray feeder specifications
Except ALL on the rear side:
Verify placement accuracy
(→P.13-21-1-1)
Calibration
Head pattern in case
of inspection head
accuracy verification
9I-ALL 18I-ALL
ALL on the rear side:
Verify accuracy of the
inspection head
■Verification order
2D inspection head
① First placement position: Offset reflection MCDATA
② First placement position: Accuracy check MCDATA
③ Second placement position: Accuracy check MCDATA
Inspection head
①Calibration STEP2 to STEP4
(→ P13-1-2)
②Accuracy verification
(→ P13-21-1)
) Specifications with the 13-slot
supply unit and the single tray
feeder installed.
NPM-W2 EJM7DE-MB-13M-00
Overview 5
(Inspection head)
Maintenance
13-21-1
Accuracy
verifica-
tion
The MCDATA (Production program) is contained in the DVD-ROM (Machine system / Recognition / LNB
system disk) that comes with the machine.
Refer to the MCDATA sheet included in the DVD-ROM, select the target MCDATA according to the machine
type. Copy it to an SD card once and load it to the machine.
An SD card should be prepared by the customer.
If you overwrite the MCDATA downloaded to the machine to the SD card, the MCDATA in the SD card will not
be functioned. If you accidentally overwrite to the SD card, copy the data from DVD-ROM again.
If you must perform accuracy verification by the configuration which is not in the MCDATA list such as head
change, please contact us.
NOTICE
13-21-1-9
NPM-W2 EJM7DE-MB-13M-00
13-21-1-10
Brief description of process
Describes the accuracy measurement procedure of the dispensing head.
The dedicated MCDATA (production
program) is used for dispensing head
accuracy verification.
1.Production
preparation
・Saving calibration DATA (DVD-ROM) to
an SD card
・Preparation for dispensing
■Working process
3.Confirmation of
accuracy
verification result
・Selection of MCDATA (Production program)
・Dispensing
・Checking of dispensing results
*1)
2.Check and
reflection of
dispensing
(offset registration)
・Selection of MCDATA (Production program)
・Dispensing
・Checking and reflection of dispensing results
*1)
MCDATA (production program)
●In the head pattern, for example, DIS-8F shows the front: Dispensing head, the rear: 8-nozzle head, and
the tape feeder supply section.
Likewise, DIS-3FT shows the front: Dispensing head, the rear: 3- nozzle head, and the single tray feeder
supply section
*2)
.
Head pattern
DIS-LW16F LW16-DIS
DIS-12F 12-DIS
DIS-8F 8-DIS
DIS-8FT(TT) 3-DIS
DIS-3F —
DIS-3FT(TT) —
The table below is the major configuration of heads and supply sections
Overview 6
(dispensing head)
Maintenance
13-21-1
Accuracy
verifica-
tion
The MCDATA (Production program) is contained in the DVD-ROM (Machine system / Recognition / LNB
system disk) that comes with the machine.
Refer to the MCDATA sheet included in the DVD-ROM, select the target MCDATA according to the machine
type. Copy it to an SD card once and load it to the machine.
An SD card should be prepared by the customer.
If you overwrite the MCDATA downloaded to the machine to the SD card, the MCDATA in the SD card will not
be functioned. If you accidentally overwrite to the SD card, copy the data from DVD-ROM again.
If you must perform accuracy verification by the configuration which is not in the MCDATA list such as head
change, please contact us.
NOTICE
LW16: Light weight 16-nozzle head
F: Tape feeder specifications
FT: Single tray feeder specifications
*2)
TT: Twin tray feeder specifications
1) Check both lanes 1 / 2.
Calibration
Accuracy verification
About the type of MCDATA, see P.13-21-1-1.
) Specifications with the 13-slot supply unit and the single tray
feeder installed
●ALL is not used for accuracy verification of the dispensing head.
