NPM-W2 EJM7DE-MB-13M-00
Checking and reflection of measurement (measurement)
ENABLING
321
(First layer)
(Second layer)
Do not press the STOP button while accuracy verification is carried out.
You cannot restart operation in the middle of accuracy verification.
NOTICE
6
Measure the
plane correction
jig
●Measure the jig in
automatic operation. After
the measurement ends
and the its operation stops,
end the automatic
operation
4
Confirm the
message
ENABLING
5
●To use accuracy verification
MCDATA:
(→ P.13-21-1
-1 ‘■Reflection
of verification data’)
13-21-2-13
Accuracy
verifica-
tion
Detailed process 7
(inspection head)
Maintenance
13-21-2
NPM-W2 EJM7DE-MB-13M-00
Checking and reflection of measurement (checking of the measurement result)
1
2
3
●2D inspection head
A type:
Resolution: 18 μm ± 0.020 mm
B type:
Resolution: 9 μm ± 0.010 mm
1
2
3
4
5
A
4
Choose a table of the
inspection head
●Cpk prescribed value per component
(→ P.9-1-1 ‘Basic performance’ in [Operating procedure] )
A
Cpk
5
Switch it with
13-21-2-14
Calibration
●When offset reflection MCDATA is
used, always reflect the inspection
camera offset.
NPM-W2 EJM7DE-MB-13M-00
Checking the measurement result (reflection of the verification data)
Confirm the message
6
6
(The data is reflected and the machine
parameter is updated)
●You can confirm the measurement accuracy result by re-measurement.
In that case, perform [Checking of measurement result] (→P.13-21-2-
14).
NOTE
13-21-2-15
Checking of measurement result
Cause Troubleshooting
The plane correction jig is
contaminated.
Check for any flaws or foreign bodies on the
surface of the jig.
Calibration jig is contaminated.
Check for any flaws or foreign bodies on the
surface of the jig.
If so, clean the surface with the provided brush and be careful not to
damage.
Machine parameters of the
inspection
head are wrong.
Execute calibration for the inspection head.
Verifies the results registered as offsets in “Checking and reflection of measurement” The procedure is the
same as the one used in “Checking and reflection of measurement”
Though not necessarily required, this procedure will be used as a guideline for measuring the level of
accuracy of the machine.
●As for MCDATA (production program), use accuracy verification MCDATA.
(→ P.13-21-1
-7 ‘■MCDATA type’)
●Accuracy verification MCDATA is intended for accuracy verification use, so refrain from reflecting in it the
each-position-angle offsets obtained from measurement results.
(→ P.13-21-1
-7 ‘■Reflection of verification data’)
The following causes are cited as possible causes when no improvements are seen in accuracy verification
results.
Accuracy
verifica-
tion
Detailed process 8
(inspection head)
Maintenance
