NPM-W2 EJM7DE-MB-15M-00 16-1 -8 Reference Inspection box No. Comp onent name Weight ( g ) Q’ty Material c omponent contents and amount (filler, reinforcement) Insert material Inspection box guide 360 1 POM (polyacetal) A…
NPM-W2 EJM7DE-MB-15M-00
Plastic parts listing 4
Maintenance
16-1
Extension conveyor
No. Component name
Weight (g)
Q’ty
Material component contents
and amount
(filler, reinforcement)
Insert material
Window on the extension
conveyor
496 1
PC
(polycarbonate)
A
A
16-1-7
NPM-W2 EJM7DE-MB-15M-00
16-1-8
Reference
Inspection box
No. Component name
Weight (g)
Q’ty
Material component contents
and amount
(filler, reinforcement)
Insert material
Inspection box guide 360 1
POM
(polyacetal)
A
A
NPM-W2 EJM7DE-MB-15M-00
Maintenance
16-2
Safety data sheet (SDS) 1
(LCG100)
16-2-1
First aid measures
Inhalation Remove to fresh air. Place a blanket, etc. over the person to keep them warm and
resting. Get medical attention as necessary.
Skin contact Remove the contaminated clothing and shoes immediately. Rinse skin with plenty of
water or hot water and soap. If suffering from contact with a heated product rinse
skin and take aid for a burn. Get medical attention as necessary if symptoms such
as a rash and pain occur.
Eye contact Wash eyes with plenty of water and get medical attention immediately. Open your
eyelids wide with fingers and wash the entire eyeball and lid with plenty of water.
When wearing contact lenses, remove them and continue washing your eyes unless
the lenses stick on your eyes.
Ingestion Do NOT induce vomiting. Get medical attention immediately. Inducing vomiting
increases risk of aspirating oil to lung. If the inside of the mouth is contaminated,
rinse it with plenty of water.
Brief information on
the most important
signs and symptoms
IF ingested, symptoms such as diarrhea and vomiting may occur.
In case of eye contact, inflammation may appear.
In case of skin contact, inflammation may appear.
If inhaling mist or vapor, symptoms such as nausea and vomiting may occur.
Extinguishing agent Dry chemical powder, foam, carbon dioxide, fog, etc. are effective.
Extinguishing agents
that cannot be used
Fog water can be used to cool down. However water jet must not be used to
extinguish fire. Otherwise fire may spread and pose a danger.
Extinguishing method
specified
Stand on the windward side as much as possible to extinguish fire. Any person other
than response personnel must not enter the fire area. Remove ignition source from
the origin of fire and use suitable agent. In case of an early stage fire, use dry
chemical powder and carbon-dioxide extinguisher. For a large-scale fire, it is
effective to use foam agent to block out air currents. Water may pose danger of
expanding the fire.
Protection of fire-
fighters
When extinguishing fire, be sure to stand on the windward side and wear protective
gear. Since there is a possibility that toxic gas (carbon monoxide, etc.) is generated
by combustion and high temperature, use a respirator.
This [Safety data sheet (SDS)] is described based on information provided by the oil manufacturer.
Oil name: LCG100
Manufactured by: Panasonic Factory Solutions Co., Ltd
Fire fighting measures
