NPM-W 2 EJM7DE-SF-01N-0 0 1-6 Disposing the gas spring The gas spring is used to open/close covers. It is ve ry dangerous to dispose of it as it is, beca use high- pressure air is sealed into it. When disposing a gas spr…
NPM-W2 EJM7DE-SF-01N-00
Product nameplate
Type of SD cards
■Key disk (Engineer)
Used when a password on each mode is changed.
●Key disk is required to set a password. Keep it in a safe place so you cannot lose it.
●Please contact us in case of loss.
■Installation disk
Used when software is stored and upgraded.
■Parameter disk
Used in saving production data and machine parameters as examples.
1-5-2
Rear side
Confirmation
The Product nameplate indicating the product name (Model ID) and serial number of the machine is affixed at
the following location.
is replaced with a numeric
value.
NPM-W2
NM-EJM7D
NPM-W2 EJM7DE-SF-01N-00
1-6
Disposing the gas
spring
The gas spring is used to open/close covers. It is very dangerous to dispose of it as it is, because high-
pressure air is sealed into it. When disposing a gas spring, be sure to degas before disposed.
To remove or dispose, please send a request to the gas spring manufacturer.
■Locations where the gas spring is used
■Removing gas spring
Turn the hexagon socket head cap screws counterclockwise and remove the spring.
●Two men should work as a team. The unintentional closing of the cover could cause injury.
■Disposing gas spring
Make a hole with the drill and degas completely inside the gas spring.
Front side
(4 locations)
Hexagon socket
head cap screw
Gas spring
Hexagon socket
head cap screw
1-6
Drilled hole
15 to 20 mm
Wear a hard hat and protective goggles
during maintenance work
(Risk of injury)
CAUTION
NPM-W2 EJM7DE-SF-01N-00
1-7
Confirmation
Handling the used
battery
This product has a battery used for controlling PCBs. Disposal may be regulated in your
community due to environmental considerations. Please dispose of or recycle it in conformity
with the laws or regulations of your country, or contact your local authorities for more
information.
ATTENTION
No. Mount location Battery type Reference page
1. CPU board Lithium battery
[Replacing the batteries]
(→P.12-3) in Maintenance
2. NCIO board Lithium battery
3. Jig station Alkaline battery
4.
FA PC：Calendar
battery（inspection
BOX）
Lithium battery
5.
FA PC：UPS
battery（inspection
BOX）
Nickel hydride
6.
FA PC：Calendar
battery（LNB）
Lithium battery
7.
FA PC：UPS
battery（LNB）
Nickel hydride
●Lithium batteries are primary batteries that cannot be recharged.
●Although manganese dioxide batteries are acceptable, alkaline batteries are recommended.
●Batteries are not included with Jig station. Please have your batteries ready.
●FA PC：Please consult us for replacing calendar battery.
EU
