Confirmation
Dispensing head (option)
Applies adhesive to PCBs with high
accuracy at the high speed.
2D inspection head
(option)
Captures the condition of the
inspection-target PCB, and outputs
the captured image to the inspection
box.
●There are two types: the one with
pixel resolutions of 18μm (type A)
and the other with 9 μm (type B).
Dummy dispensing unit
(option)
Rolls up the dummy tape during dummy dispensing.
Calibration jig for the 2D
inspection 2D
(option)
An optical reference plate used
in calibration of the 2D
inspection head.
