NPM-W2 EJM7DE-MB-02M-00
2-1-2-7
Periodic inspection
items by cycle 4
Maintenance
2-1-2
Over-
view
■ Light weight 16-nozzle head (option), 12-nozzle head (option),
8-nozzle head (option)
No. Unit Check and greasing location Power
Check and
greasing points
Time
[min]
Ref.
1
Nozzle holder
(per head)
Spring for nozzle cushion
OFF Cleaning 40
*1)
7-1
Inner and outer circumferences
Spring for holding clamp claws
Clamp claw
Filter
Taper surface
Nozzle-holder shaft
Nozzle-holder shaft OFF Cleaning
148
*2)
Nozzle holder slicing surface
OFF Cleaning
OFF
Grease dispensing
(FL100)
*1) Time required for the light weight 16-nozzle head. The time required for the 12- and 8-nozzle
heads is 35 and 30 minutes, respectively.
*2) Time required for the light weight 16-nozzle head. The time required for the 12- and 8-nozzle
heads is 116 and 84 minutes, respectively.
The time required to inspect the light weight 16-nozzle head (min) = 188 x (the number of
heads)
Every-1000-hours (monthly) inspection items
NPM-W2 EJM7DE-MB-02M-00
Every-3000-hours (every 6 months) inspection items
Every-6000-hours (yearly) inspection items
■ 3-nozzle head (Option)
■ Types in common
■ Types in common
No. Unit Check and greasing location Power
Check and
greasing points
Time
[min]
Ref.
1 Touch screen
Backlight
ON
Check 1 9-1
Hinge (Front and rear sides)
Grease
dispensing
(TOUCH LUBE)
19-2
No. Unit Check and greasing location Power
Check and
greasing points
Time
[min]
Ref.
1 Nozzle 1006 nozzle OFF Check 1 9-3
Inspection time (min) = 20
Inspection time (min) = 7
Inspection time (min) = 1 x (the number of nozzles)
■ 2D inspection head (option)
No. Unit Check and greasing location Power
Check and
greasing points
Time
[min]
Ref.
1 Inspection BOX Filter (FA computer) OFF Cleaning 15 8-2
2 2D inspection head Camera ON
Correction of color
and brightness
20 8-5
Inspection time (min) = 35
■ Dispensing head (option)
No. Unit Check and greasing location Power
Check and
greasing points
Time
[min]
Ref.
1 Dispensing head O-ring ON Replacement
20 8-3
2 Screw unit
O-ring ON Replacement
Collar ON Replacement 10 8-4
Inspection time (min) = 30 x (the number of heads)
No. Unit Check and greasing location Power
Check and
greasing points
Time
[min]
Ref.
1 Main controller Filter OFF Cleaning 20 8-1
2-1-2-8
Overview
NPM-W2 EJM7DE-MB-02M-00
Every-18000-hours (every 3 years) inspection items
■ Types in common
■ Light weight 16-nozzle head (Option), 12-nozzle head (Option), 8-nozzle head (Option)
■ 3-nozzle head (Option)
No. Unit Check and greasing location Power
Check and
greasing points
Time
[min]
Ref.
1 XY unit Cable bearer OFF Check 5 10-2
No. Unit Check and greasing location Power
Check and
greasing points
Time
[min]
Ref.
1
Nozzle holder
(per head)
Clamp claw
OFF Check 20
*5)
10-1Spring for holding clamp claws
Spring for nozzle cushion
No. Unit Check and greasing location Power
Check and
greasing points
Time
[min]
Ref.
1
Nozzle holder
(per head)
Clamp claw
OFF Check 10 10-1
Spring for holding clamp claws
*5) Time required for the light weight 16-nozzle head. The 12- and 8-nozzle heads require 15 and
10 minutes, respectively.
Inspection time (min) = 5
The time required to inspect the light weight 16-nozzle head (min)
= 20 x (the number of heads)
Inspection time (min) = 10 x (the number of heads)
■ Dispensing head (option)
No. Unit Check and greasing location Power
Check and
greasing points
Time
[min]
Ref.
1 Dispensing head
Spring ON
Replacement
15 10-3
Heater/
Thermocouple
– – 10-4
2 Screw unit Spring ON Replacement 10 10-3
3
Dummy dispensing
unit
Spring ON Replacement 10 10-3
Inspection time (min) ＝35 x (the number of heads)
