NPM-W2 EJM7DE-MB-02M-00
Over-
view
Periodic inspection items
by applying grease
2-1-4
Maintenance
2-1-4
Grease dispensing
The lists below show grease locations and names organized by the target unit.
Apply grease
Overview
No.
Unit Location Grease
Cycle
[h]
Ref.
1
Nozzle holders
(Light weight 16-, 12- and 8-
nozzles)
Nozzle holder slicing
surface
FL100
140 7-1
Clamp claw BARRIERTA IEL/V 560 6-3
2
Nozzle holders
(3-nozzle)
Clamp claw BARRIERTA IEL/V 560 5-2
3
PCB conveyor
(single conveyor)
Linear guide LCG100 560
6-1
4
PCB conveyor
(dual conveyor)
Linear guide
LCG100 560
Ball spline
5
Nozzle holders
(Light weight 16-, 12- and 8-
nozzles)
Spring for holding
clamp claw
BARRIERTA IEL/V 560 6-3
6
Tray feeder drawer
(Option)
Linear guide
LCG100 560 6-13
Cam plate (inside)
Cam block
7
Dummy dispensing unit
(option)
Linear guide
LCG100 560 6-20
Rack & pinion
8 Touchscreen Hinge TOUCH LUBE 6000 9-2
No.
Unit Location Grease
Amount
[cm
3
]
Cycle
[h]
Ref.
1
PCB conveyor (single
conveyor)
Width-adjustment ball
screw
LCG100 1.8 560 6-1
PCB conveyor (dual
conveyor)
Width-adjustment ball
screw
LCG100 3.6 560 6-1
2 XY unit
X-axis linear guide
LCG100
2
560 6-2
Y-axis linear guide 4
3 Feeder cart Cutting unit LCG100 2.7 560 6-17
4
Tray feeder lifter
*7)
(option)
Ball screw
LCG100
1.8
560 6-13
Linear guide 7.2
5 13-slot feeder Cutting unit LCG100 1.8 560 6-17
6 Dispensing had (option)
Ball screw
LCG100
0.6
560 6-19
Linear guide 0.6
*7) The lubrication quantity required for the twin tray feeder is twice as great as the amount for the tray
feeder.
NPM-W2 EJM7DE-MB-02M-00
Type in common
2-1-5-1
Consumable parts
Maintenance
2-1-5
Option
Over-
view
No. Name
Life expectancy
[h]
Remarks Reference
1Clamp claw
18000 – 10-12 Spring for holding clamp claws
3 Spring for nozzle cushion
4 Air Filter element 6000 – 12-6
■ Light weight 16-nozzle head
No. Name
Life expectancy
[h]
Remarks Reference
1Clamp claw
18000 – 10-12 Spring for holding clamp claws
3 Spring for nozzle cushion
4 Air Filter element 6000 – 12-7
■ 12-nozzle head
No. Name
Life expectancy
[h]
Remarks Reference
1Clamp claw
18000 – 10-12 Spring for holding clamp claws
3 Spring for nozzle cushion
4 Air Filter element 6000 – 12-8
■ 8-nozzle head
No. Name
Life expectancy
[h]
Remarks Reference
1
PCB transfer belt
(PCB single conveyor)
––
12-1
PCB transfer belt
(PCB dual conveyor)
2
PCB transfer belt
(Extension single conveyor)
12-2
PCB transfer belt
(Extension dual conveyor)
3 CPU board battery
60000 10 years
12-34 NCIO board battery
5 Jig station battery (8760) 1 year
NPM-W2 EJM7DE-MB-02M-00
2-1-5-2
No. Name
Life expectancy
[h]
Remarks Reference
1 O-ring (Dispensing head) 3000
–
8-3
2 Spring (Dispensing head) 18000 10-3
3
Heater/Thermocouple (Dispensing
head)
18000 10-4
4 O-ring (Screw unit) 3000 8-3
5 Collar (Screw unit) 3000 8-4
6 Spring (Screw unit) 18000 10-3
7 Spring (Dummy dispensing unit) 18000 10-3
8
Dummy dispensing tape (Dummy
dispensing unit)
– 12-4
9 Cushion (wiping station) – 12-5
■ Dispensing head
No. Name
Life expectancy
[h]
Remarks Reference
1
FA computer: Calendar battery
(87600) 10 years
12-3
2
FA computer: UPS battery
(26280) 3 years
■Inspection head
Overview
No. Name
Life expectancy
[h]
Remarks Reference
1Clamp claw
18000
–
10-1
2 Spring for holding clamp claws
3 Air Filter element 6000 12-9
■ 3-nozzle head
No. Name
Life expectancy
[h]
Remarks Reference
1
FA computer: Calendar battery
(87600) 10 years
12-3
2
FA computer: UPS battery
(26280) 3 years
■LNB
