6.10.1. 带式喂料器（Tape feeder）
8mm, 12mm, 16mm, 24mm, 32mm, 44mm, 56mm, 72mm 共有8种。
图 6-11. 带式喂料器（Tape Feeder）
1: Swing Lever 2: Location Flange 3: Locker 4: Ratchet
5: Sprocket 6: Clamping Roller 7: Shutter 8: Tape Guide
9: Install Guide 10: Probe Pin 11: Drain Gear 12: Forming Gear
13: PCB Cover 14: Reel Hanger 15: Lever BKT2 16: Grip
17: V LOC Pin 18: Pusher Lever 19: Serial No.
Sticker
1
3
7
5
4
10
17
18
2
6
8
9
11
12
13
14
15
16
19
Module Function
6-15
以 8mm 带式喂料器(Tape Feeder)为准时，前后面可安装各 60 个，共计 120 个。
1005 chip时，使用专用8.0mm 带式喂料器(Tape Feeder)。
6.10.1.1. 带式喂料器（Tape Feeder） 规格
带式喂料器（Tape Feeder）种类及移动间距
表
6-1.
带式喂料器（
Tape Feeder
）种类及移动间距
品 名 部品编号 移动间距 (mm)
SM IT 8mm 0603 Tape Feeder 8 0603 专用
SM IT 8mm 2P Tape Feeder 8 1005 及 2 Emboss Tape 专用
SM IT 8mm 4P Tape Feeder 8 4 Paper Tape 专用
SM IT 8mm 4E Tape Feeder 8 4 Emboss Tape 专用
SM IT 12mm Tape Feeder 12 4, 8, 12
SM IT 16mm Tape Feeder 16 4, 8, 12, 16
SM IT 24mm Tape Feeder 24 4, 8, 12, 16, 20
SM IT 32mm S Tape Feeder 32 4, 8, 12, 16, 20
SM IT 32mm L Tape Feeder 32 20, 24, 32
SM IT 44mm S Tape Feeder 44 4, 8, 12, 16, 20
SM IT 44mm L Tape Feeder 44 20, 24, 32, 40
SM IT 56mm S Tape Feeder 56 4, 8, 12, 16, 20
SM IT 56mm Tape Feeder 56 20, 24, 32, 40
IT Tape
Feeder
SM IT 72mm Tape Feeder 72 4, 8, 12, 16, 20, 24, 32, 40
SM NonIT 8mm 0603 Tape Feeder 8 0603 专用
SM NonIT 8mm 2P Tape Feeder 8 1005 及 2 Emboss Tape 专用
SM NonIT 8mm 4P Tape Feeder 8 4 Paper Tape 专用
SM NonIT 8mm 4E Tape Feeder 8 4 Emboss Tape 专用
SM NonIT 12mm Tape Feeder 12 4, 8, 12
SM NonIT 16mm Tape Feeder 16 4, 8, 12, 16
SM NonIT 24mm Tape Feeder 24 4, 8, 12, 16, 20
SM NonIT 32mm S Tape Feeder 32 4, 8, 12, 16, 20
SM NonIT 32mm L Tape Feeder 32 20, 24, 32
SM NonIT 44mm S Tape Feeder 44 4, 8, 12, 16, 20
SM NonIT 44mm L Tape Feeder 44 20, 24, 32, 40
SM NonIT 56mm S Tape Feeder 56 4, 8, 12, 16, 20
SM NonIT 56mm Tape Feeder 56 20, 24, 32, 40
Non IT
Tape
Feeder
SM NonIT 72mm Tape Feeder 72 4, 8, 12, 16, 20, 24, 32, 40
备注
Samsung Component Placer SM411 Introduction
6-16
可适用Reel
SM Tape Feeder 对应可能的卷（reel）直径请参照下表。此时，SM 8mm Tape
Feeder 的 卷（reel）宽度(W2)应在 13.0mm 以内。
表
6-2. SM Tape Feeder
使用可能的卷（
reel
）直径
品 名 Tape 侧 卷（reel）直径 “A”(mm)
SM 8mm Tape Feeder 8mm φ178,φ180
SM 12mm Tape Feeder 12mm φ178,φ180, φ254,φ330,φ380
SM 16mm Tape Feeder 16mm φ178,φ180, φ254,φ330,φ380
SM 24mm Tape Feeder 24mm φ178,φ180, φ254,φ330,φ380
SM 32mm Tape Feeder 32mm φ178,φ180, φ254,φ330,φ380
SM 44mm Tape Feeder 44mm φ178,φ180, φ254,φ330,φ380
SM 56mm Tape Feeder 56mm φ178,φ180, φ254,φ330,φ380
IT /
Non IT
Tape
Feeder
SM 72mm Tape Feeder 72mm φ178,φ180, φ254,φ330,φ380
图
6-12. Reel
値數
适用部品
四角chip, MELF, TR, SOP, PLCC, 异形(Odd-type) 部品等
(SM 8mm Emboss Tape的T2为Max 3.5 mm，B1为Max 4.35 mm。)
图
6-13. Embossed Carrier Tape (8/12mm)
