Page SAMSUNG TECHWIN 105 SLM120/110 E lectric Panel Ass’y No. LEVEL P ART No. P ART NAME Q'TY T YPE Old No. Stock Apply Reference
Page
SAMSUNG TECHWIN
104
SLM120/110
Electric Panel Ass’y
No. LEVEL PART No. PART NAME Q'TY TYPE Old No. Stock Apply Reference
25 J31531042A
SERVO_MOTOR_DRV_30A_RS2A03A0AL0W00
2
26 J31531043A
SERVO_MOTOR_DRV_50A_RS2A05A0AA0W00
2
27 J3105010A
COOLING FAN[4715MS-22T-B50]
1
28 J6103005A
HEX SUPPORT
10
29 J61031003A
HEX-SUPPORT M3*35 (BOLT-NUT)
6
30 J91741194A
SM431_SAFETY_FROP_BOARD_ASSY SAFROP_REV.
1
31 J72611004A
AP5_POWER_WIRING_DUCT J72611004A
1
32 J20291006A
REGENERATIVE RESISTOR[ULF250C] ULF250C
1
33 J20291007A
REGENERATIVE RESISTOR[ULF500CI] ULF500C
1
34 EP23-000092 TRANSFORMER 1 J26051012A/ EP23-000002
35 J31521023A STEPPING_MOTOR_DRIVER 1
36
Page
SAMSUNG TECHWIN
105
SLM120/110
Electric Panel Ass’y
No. LEVEL PART No. PART NAME Q'TY TYPE Old No. Stock Apply Reference
Page
SAMSUNG TECHWIN
106
SLM120/110
Electric Device Ass’y (1/2)
10
6
1
17
13
14
9
5
5
8
11
2
12
15
16
3
18
4
7
