System Requirements
Computers
Version Description / Versionsbeschreibung SIPLACE Setup Center 5.1 39
4 System Requirements
4.1 Computers
4.2 Resource Requirements
NOTICE
NTFS partitioning
SIPLACE Setup Center requires a NTFS partitioning for installation. FAT or FAT32 file systems
are not supported.
Installation of SIPLACE Setup Center onto a FAT partitioning will be interrupted by the setup
program.
NOTICE
Licence Manager 2.3
SIPLACE Setup Center 5.1 requires license manager 2.3 for operation.
Depending on the selected function, one or more licenses are required for operating Setup
Center.
NOTICE
System requirements
The system requirements (supported operating system and database variants) and an over
-
view of mutually compatible products can be found in the Assembly Instructions SIPLACE Sup
-
port Media, item no [00197214-xx].
NOTICE
The size of the database server depends on the amount of the packaging unit data.
► Large data amounts require a higher server performance.
Hard Disk Main Memory
▪ Windows approx. 2500 MB
▪ Program files approx. 90 MB
▪ Database = number of recorded batches x 1
KB
▪ Windows approx. 200 MB
▪ SQL Server with Setup Center database ap
-
prox. 150 MB
▪ Setup Center GUI approx. 100 MB
System Requirements
Supported Software
40 Version Description / Versionsbeschreibung SIPLACE Setup Center 5.1
4.3 Supported Software
Programming system
SIPLACE Setup Center supports the following version in online and offline mode:
Station software
SIPLACE Setup Center supports the following station software versions:
Pre-setup unit for X tables
The pre-setup unit for X tables (docking station) requires the following:
SIPLACE Pro Interface version SIPLACE Pro Desk version
5.0 SP1, 5.2, 6.0, 7.0,8.0, 9.2, 9.3 ,10.0 or 10.1 5.0 SP1, 5.2, 6.0, 7.0, 8.0, 9.2 , 9.3, 10.0 or 10.1
Forced setup verification Unforced setup verification
407.05 (Hotfix 3), 505.05SP1 and 605.01SP2 10x, 40x, 50x, 60x and 70x
703.xx, 704.xx, 705.xx and higher
CAN bus PCI card X FCU X Feeders
Sontheim PCI CAN driver 6.2.4.0
or higher version (on the product
CD)
The version can be upgraded
with Setup Center.
The version can be upgraded
with Setup Center.
System Requirements
Supported Hardware
Version Description / Versionsbeschreibung SIPLACE Setup Center 5.1 41
4.4 Supported Hardware
Supported barcode readers
▪ Datalogic DRAGON TM M101 (1D barcode)
▪ Datalogic DRAGON TM M131 (1D barcode)
▪ Datalogic PowerScan® M8300 (1D-Barcode)
▪ Datalogic PowerScan® M8500 (2D-Barcode)
▪ Datalogic PowerScan® BT8300 (1D barcode
▪ Symbol MC70 Pocket-PC (2D barcode)
▪ Motorola MC70 Pocket-PC (2D barcode)
▪ Motorola MC75 Pocket-PC (2D barcode)
Supported barcode types
▪ Datalogic 1D barcode scanner:
– Automatic recognition of all standard linear codes and linear GS1 DataBar ™ codes.
– Code 16K; Code 49; GS1 DataBar Expanded Stacked; GS1 DataBar Stacked; GS1 DataBar
Stacked Omnidirectional
▪ Datalogic 2D barcode scanner:
– Automatic recognition of all standard linear codes and linear GS1 DataBar ™ codes.
– Aztec Code; Aztec Mesas; Data Matrix; MaxiCode; QR Code; Post Codes; Australian Post; Brit
-
ish Post; Canadian Post; China Post; Japanese Post; KIX Post; Korea Post; Planet Code; Post
-
net; Royal Mail; Code (RM4SCC) ; EAN/JAN Composites; GS1 DataBar Composites; GS1
DataBar Expanded Stacked; GS1 DataBar Stacked; GS1 DataBar Stacked Omnidirectional;
MacroPDF; MicroPDF417; PDF417; UPC A/E Composites
▪ Symbol / Motorola 2D barcode scanner:
– AusPostal, Aztec, Chinese_2of5, Codabar, Code11, Code128, Code39, Code93, Composite
AB, Composite C, D2of5, Datamatrix, DutschPostal, EAN13, EAN8, I2of5, JapPostal,
Korean_3of5, MaixiCode, MicroPDF, MicroQR, MSI, PDF417, QRCode, RSS14, RSSExp,
RSSLim TLC39, Trioptic39, UKPostal, UPCA, UPCE0, UPCE1, US4State, US4State_FICS, US
-
Planet, USPostnet, WebCode
Supported machines
Machine
SIPLACE 80 F4, F4-6, S20; F5, F5 HM, S23
SIPLACE S25 HM, S27 HM, HS50, HS 50+, HS60, HF,
HF3
SIPLACE X2, X3, X4; D1, D2, D3, D4
SIPLACE CF, CS
SIPLACE X2, X3, X4, X4I
SIPLACE SX1, SX2, SX4, SX1 V2, SX2 V2
SIPLACE DX1, DX2, DX4
SIPLACE X4i S, X4 S, X3 S
NOTICE
Restrictions
Please note that the programming system SIPLACE Pro and the Setup Center station package
may limit this selection.
