Notes: Part 3 Chapter 1 Cleaning Edition 3.1 3-1-14 XP-142E Mechanical Reference

3. Remove the drain hose, if one is used on the machine.

4. Hold the lock button down and rotate the filter case to remove it.

5. Remove any water that has collected in the filter case, and use a neutral detergent

to clean the case. Clean the inside of the filter with compressed air, or replace it if

necessary.

Cleaning Checklist

T012Ed

Cleaning Interval

Every 8 hours

Everyday

Weekly

Every 3,000 hours

Weekly

Every 3 months

Monthly

CheckPlace Cleaned

Waste Tape Box <if so equipped>

Parts Reject Box and Tray

Nozzle Interior

Gauge Chip Parts

Vacuum Pump Filter

Machine Interior

Strobe Light Half Mirror

Strobe Light Unit

Regulator Filter

1.1

1.2

1.3

1.4

1.5

1.6

1.7

1.8

1.9

XP1MC212E

Lock button

Drain hose

Filter case

Part 3 Chapter 1 Cleaning

Edition 3.1 3-1-13 XP-142E Mechanical Reference

Notes:

Part 3 Chapter 1 Cleaning

Edition 3.1 3-1-14 XP-142E Mechanical Reference

2. Lubrication

Precautions During Lubrication

• Prior to beginning any lubrication, turn the main breaker to off.

• Apply an appropriate amount of lubricant. If too much lubricant is applied, it

may splatter and drop on boards inside the machine. Special care should be taken

to keep the camera lens clean for stable part inspection. Use a lens cleaner to keep

the lens clean.

Types of Lubricants

The lubricants that are used have the following characteristics.

Daphne Eponex No. 2

Biral T&D

Lithium grease by Idemitsu suited to mid/low speed parts.

Anticorrosive spray on oil suited to low speed, low load

parts.

Characteristics

T011E

Type

AFC Grease

High grade synthetic oil based on grease by THK suited to

high speed parts.

Part 3 Chapter 2 Lubrication

Edition 3.0 3-2-1 XP-142E Mechanical Reference
