Station Software 704.03 SP1 / Installation Manual Ausgabe 10/2011 Edition
2 Scope of delivery
2.1 Software components
704.03 SP1 software
Standard package: 00140030-04 Software SIPLACE Station 704.03 SP1 Basic
– Software CD-ROM
(1)
– License/product certificate
– Software Installation Manual V704.03 SP1 D+E (00196715-04)
– Packaging
Languages: 00140031-04 SIPLACE foreign language software SC 704.03 SP1
– CD-ROM with software (language pack)
– License/product certificate
– Software Version Description for foreign languages V704.03 SP1 D+E (00196716-04)
– Packaging
(1)
The standard applications are contained on the CD:
– Embedded software for conveyor
– Embedded software for axes
– Embedded software for component tables
– Embedded software for tape cutter
– Embedded software for heads
– Embedded software for vision modules
– Embedded software for I/O modules
– Embedded software for X-feeders
– Embedded software for digital pressure regulation valve
– Embedded software for MTC2
– Embedded software for WPC5/WPC6
2.2 Hardware components
– Machine computer
– Vision computer (optional)
6
Station Software 704.03 SP1 / Installation Manual Ausgabe 10/2011 Edition
2.3 Languages
SIPLACE Station and SIPLACE Vision GUI:
The standard package contains German and English versions.
Other languages are contained in the optional languages package and available under item
number 00140031-04.
The following table indicates which languages are available for the station software and SIPLACE
Vision:
Language Station software /
SIPLACE Vision
French x
Italian x
Spanish (Mexico) x
Portuguese (Brazil) x
Czech
*)
x
Polish
*)
x
Hungarian x
Romanian
*)
x
Chinese (simplified) x
Korean x
Table 2-1: Languages
*)
GUI only (online help English)
7
Station Software 704.03 SP1 / Installation Manual Ausgabe 10/2011 Edition
3 Upgrading to the 704.03 SP1 software version
This chapter describes which steps you have to attend when upgrading from different software
versions.
When upgrading the station software, always check the eSW versions and download the current
versions if necessary.
NOTICE
– With the installation of the 704.03 SP1 station software, statistic data (maintenance
intervals) is registered for the CPP placement head and the SX main axis. In order to
achieve a defined initial state for the maintenance due, the correspondent
maintenance operations have to be performed on the subsystems after the software
installation.
– An upgrade of the embedded software is necessary for the LDU-X. Generally, it is
not possible to perform a download of the embedded software via the station
software for the LDU-X. The LDU-X has to be upgraded to the 2.02 software version
with the aid of an external PC.
3.1 Upgrading from the 704.xx software version
► Recalibrate the travelling ranges.
The travelling range measurement has been improved in 704.03 SP1. For this reason you are
advised to recalibrate the travelling ranges during installation of the 704.03 SP1 station
software.
► Recalibrate the external cameras.
This is required, as the z height has been adapted for the dp calibration.
► Save the calibration data for the placement heads (except Twin Head) in the EEPROM
(see section 7.8).
► Perform a component sensor calibration if a CPP placement head is used for 0201/01005
placement.
3.2 Upgrading from the 703.02 or 703.02 SP1 software versions
► Please pay attention to the Technical Informations TI2010-10V02 and TI2010-10C02 when you
download the embedded software.
► Recalibrate the travelling ranges.
► Recalibrate the external cameras.
This is required, as the z height has been adapted for the dp calibration.
► SX-series placement machines in the field:
Due to the SW component counter, the HCU/GCU and the sensor modules have to be
programmed. For this, perform the work steps that are described in the Technical Informations
TI2010-02V01 and TI2010-02C01 about programming HCU/GCU for the 704 upgrade. These
work steps can only be performed by SIPLACE Service.
