GEM for SIPLACE V5.01
©Siemens AG, all rights reserved page 121 of 252
 6WUHDP
 6)7HUPLQDO5HTXHVW
S10F1 [W] * H<-E
<L [2]
<B [1] TID> * Terminal ID
<A [160] TEXT> * Message Text
> .
The Equipment sends text to the Host. This Equipment may send the following values for
TID:
TID Description
0x00 Always sent.
Equipment Constant "WBitS10" controls whether the Equipment sends S10F1 with W-Bit
"1" (Reply Expected) or "0" (No Reply Expected).
 6)7HUPLQDO5HTXHVW$FNQRZOHGJH
S10F2 * H->E
<B [1] ACKC10> . * Acknowledge Code
The Host may send the following values for ACKC10:
ACKC10 Description
0x00 Normal. Host accepts the S10F1.
Other Host rejects the S10F1.
 6)7HUPLQDO'LVSOD\
S10F3 [W] * H->E
<L [2]
<B [1] TID> * Terminal ID
<A [160] TEXT> * Message Text
> .
The Host sends to the Equipment. The Equipment interprets TID as follows:
TID Description
Any Equipment displays the text on its CRT.
The Host may optionally set the W-Bit to "1" in S10F3. If so, the Equipment replies with
S10F4.
 6)7HUPLQDO'LVSOD\6LQJOH$FNQRZ OHGJH
S10F4 * H<-E
<B [1] ACKC10> . * Acknowledge Code
GEM for SIPLACE V5.01
Page 122 of 252 ©Siemens AG, all rights reserved
This Equipment may send the following values for ACKC10:
ACKC10 Description
0x00 Normal.
 6)7HUPLQDO'LVSOD\0 XOWLEORFN
S10F5 [W] * H->E, Multiblock
<L [2]
<B [1] TID> * Terminal ID
<L
<A [160] TEXT> * Message Text
...
>
> .
S10F5 can contain multiple TEXT data items. Each TEXT data item is limited to 160
characters. Each data item in S10F5 will be displayed on a separate line at the
equipment.
The Host sends text to the Equipment. The Equipment interprets TID as follows:
TID Description
Any Equipment displays the text on its CRT.
The Host may optionally set the W-Bit to "1" in S10F5. If so, the Equipment replies with
S10F6.
 6)7HUPLQDO'LVSOD\0 XOWLEORFN$FNQRZOHGJH
S10F6 * H<-E
<B [1] ACKC10> . * Acknowledge Code
This Equipment may send the following values for ACKC10:
ACKC10 Description
0x00 Normal.
 6)%URDGFDVW
S10F9 [W] * H->E
<A [160] TEXT> . * Message Text
The Host sends text to the Equipment. The Equipment displays the text on its CRT.
The Host may optionally set the W-Bit to "1" in S10F9. If so, the Equipment replies with
S10F10.
GEM for SIPLACE V5.01
©Siemens AG, all rights reserved page 123 of 252
 6)%URDGFDVW
S10F10 * H<-E
<B [1] ACKC10> . * Acknowledge Code
This Equipment may send the following values for ACKC10:
ACKC10 Description
0x00 Normal.
