GEM for SIPLACE V5.01 Page 142 of 252 ©Siemens AG, all rights reserved  2SHUDWRU&RPPDQG6XFFHVVIXO Step SECS Mess age De scription 1. ControlState is Local. T he operator issues a front-panel INIT IAT E PROCE…

GEM for SIPLACE V5.01

1. H -> E S2F41 [W] The Host sends the command. The W-bit in this

message may be either 0 or 1.

2. H <- E S2F42 If the W-bit in S2F41 is 1, the Equipment

acknowledges the command. The acknowledge

code in this message is 64 (Control State is

incorrect). If the W-bit is 0, this message is not

sent. In either case, the Equipment does not

perform the command.

 *R5HPRWH2SHUDWRU,QLWLDWHG

Step SECS Message Description

1. ControlState is Local. The Equipment operator

switches the Equipment to Remote Control.

2. H <- E S6F11 W The Equipment signals CEID GemControlState

REMOTE. Event Reports as appropriate.

3. H -> E S6F12 The Host acknowledges the report.

 *R/RFDO2SHUDWRU,QLWLDWHG

Step SECS Message Description

1. ControlState is Remote. The Equipment

operator switches the Equipment to Local

Control.

2. H <- E S6F11 W The Equipment signals CEID GemControlState

LOCAL. Event Reports as appropriate.

3. H -> E S6F12 The Host acknowledges the report.

GEM for SIPLACE V5.01

 2SHUDWRU&RPPDQG6XFFHVVIXO

Step SECS Message Description

1. ControlState is Local. The operator issues a

front-panel INITIATE PROCESS command. The

Equipment performs the command.

2. H <- E S6F11 W The Equipment signals CEID LotStart. Event

Reports as appropriate.

3. H -> E S6F12 The Host acknowledges the report.

GEM for SIPLACE V5.01

 3URFHVV3URJUDP

 8QIRUPDWWHG+RVW,QLWLDWHG

Step SECS Message Description

1. H -> E S7F1 W Host requests permission to send a multi-block

Process Program to the Equipment. If the

Process Program is single-block, this step and

the next one may be skipped.

2. H <- E S7F2 The Equipment grants permission for the Host to

send the Process Program.

3. H -> E S7F3 W Host sends the process Program to the

Equipment.

4. H <- E S7F4 The Equipment acknowledges receipt of the

Process Program. The Equipment checks the

received Process Program for validity. If the

process Program is valid, the Equipment stores

the Process Program in its library and sends an

acknowledge code of zero in this message. If

the Process Program is not valid, or could not be

stored in the library, the acknowledge code in

this message is non-zero.

 8QIRUPDWWHG+RVW,QLWLDWHG

Step SECS Message Description

1. H -> E S7F5 W Host requests a Process Program from the

Equipment library.

2. H <- E S7F5 The Equipment sends the Process Program. If

the Process Program does not exist, the data

portion of this message is an empty list.

 8QIRUPDWWHG(TXLSPHQW,QLWLDWHG

Step SECS Message Description

1. H <- E S7F5 W Equipment requests a Process Program.

2. H -> E S7F6 The Host sends the Process Program. If the

Process Program is valid, the Equipment stores

the Process Program in its library, and the

scenario ends. If the data portion of S7F6 is an

empty list, or if the Process Program is not valid,

the Equipment does not store it in its library and

the scenario continues.

3. H <- E S6F11 W The Equipment sets „PPCHANGENAME“ to the

requested PPID and signals CEID

GemBadDownloadEvent. Event reports as

appropriate.

4. H -> E S6F12 The Host acknowledges the report.
