GEM for SIPLACE V5.01 ©Siemens AG, all rights r eserved page 155 of 252 9,' &ODVV )RUPDW 1DPHDQG'HVFULSWLRQ The s tate of the center c onveyor 0 = Empty 1 = Full 2 = Erro r 612003 SV U1 OUTPUT CONVEYORST …
GEM for SIPLACE V5.01
Page 154 of 252 ©Siemens AG, all rights reserved
9,' &ODVV )RUPDW 1DPHDQG'HVFULSWLRQ
Fiducials
412001 SV L TAUGHTFIDUCIAL
Name of the last fiducial taught.
/
8)LGXFDO1DPH!
84XDOLW\!>@
!
412002 SV L FIDUCIALDATA
Result from the last fiducial measurement
/
8)LGXFDO1DPH!
,4XDOLW\!>@
8;SRVLWLRQ!>PP@
8<SRVLWLRQ!>PP@
8;GHYLDWLRQ!>PP@
8<GHYLDWLRQ!>PP@
!
For a detailed description of the data item see „4.2
Data Item Dictionary“.
An empty list indicates an error.
Vision
512001 SV A MODIFIEDPACKAGEFORM
Name of the last package form which was modified at
the SIPLACE
/
83DFNDJH)RUP!
86HQVRU!
!
SIPLACE Transport
612001 SV U1 INPUTCONVEYORSTATE
The state of the input conveyor.
0 = Empty
1 = Full
2 = Error
612002 SV U1 CENTERCONVEYORSATE.
GEM for SIPLACE V5.01
©Siemens AG, all rights reserved page 155 of 252
9,' &ODVV )RUPDW 1DPHDQG'HVFULSWLRQ
The state of the center conveyor
0 = Empty
1 = Full
2 = Error
612003 SV U1 OUTPUTCONVEYORSTATE.
The state of output conveyor.
0 = Empty
1 = Full
2 = Error
612004 SV U1 TWININPUTCONVEYORSTATE.
The state of the input conveyor. on twin side
0 = Empty
1 = Full
2 = Error
612005 SV U1 TWINCENTERCONVEYORSTATE.
The state of the center conveyor on twin side
0 = Empty
1 = Full
2 = Error
612006 SV U1 TWINOUTPUTCONVEYORSTATE.
The state of output conveyor on twin side.
0 = Empty
1 = Full
2 = Error
612007 SV I4 TRANSPORTWIDTH
transport width [1/1000 mm]
A value of -1 indicates an error
612008 SV I4 TWINTRANSPORTWIDTH
transport width [1/1000 mm] on twin side
A value of -1 indicates an error
Waffle Pack Changer
812001 SV L INVENTARYWPC.
Only valid after the first „WPCinvetStatus“ event.
Inventory status waffle pack changer.
/
/
$&RPSRQHQW1DPH!
,/HYHO!
GEM for SIPLACE V5.01
Page 156 of 252 ©Siemens AG, all rights reserved
9,' &ODVV )RUPDW 1DPHDQG'HVFULSWLRQ
,'LYLVLRQ!
8&RPS&RXQW!
!
!
For a detailed description of the data item see „4.2
Data Item Dictionary“.
An empty list indicates an error.
Barcode
912001 SV A BCINCENTERCONVEYOR
Barcode read from PCB in center conveyor. If no
barcode reader is installed in SIPLACE this variable
will contain an empty text
An empty text indicates an error.
912002 SV A BCININPUTCONVEYOR
Barcode read from PCB in input conveyor. If no
barcode reader is installed in SIPLACE this variable
will contain an empty text
An empty text indicates an error.
912003 DV A COMPONENTBARCODE
Component barcode is read by the GUI.
An empty text indicates an error.
912004 DV U2 WAYOFINPUTCOMPONENTBARCODE
Way of reading the component barcode:
1: with keyboard
2: with barcode reader
912005 SV U2 PCBSIDEININPUTCONVEYOR
Side of the PCB showing the barcode
1: above (barcode reader manufactured by SICK)
2: down (barcode reader manufactured by SICK)
3: barcode reader manufctured by LEUTZE in use RU
the barcode could not be read
912006 SV U2 PCBSIDEINCENTERCONVEYOR
Side of the PCB showing the barcode
1: above (barcode reader manufactured by SICK)
2: down (barcode reader manufactured by SICK)
3: barcode reader manufctured by LEUTZE in use RU
the barcode could not be read
