GEM for SIPLACE V5.01
©Siemens AG, all rights reserved page 157 of 252
9,' &ODVV )RUPDW 1DPHDQG'HVFULSWLRQ
912011 SV A BCINTWINCENTERCONVEYOR
Barcode read from PCB in twin center conveyor. If no
barcode reader is installed in SIPLACE this variable
will contain an empty text.
An empty text indicates an error.
912012 SV A BCINTWININPUTCONVEYOR
Barcode read from PCB in twin input conveyor. If no
barcode reader is installed in SIPLACE this variable
will contain an empty text.
An empty text indicates an error.
912015 SV U2 PCBSIDEINTWININPUTCONVEYOR
Side of the PCB showing the barcode
1: above (barcode reader manufactured by SICK)
2: down (barcode reader manufactured by SICK)
3: barcode reader manufctured by LEUTZE in use RU
the barcode could not be read
912016 SV U2 PCBSIDEINTWINCENTERCONVEYOR
Side of the PCB showing the barcode
1: above (barcode reader manufactured by SICK)
2: down (barcode reader manufactured by SICK)
3: barcode reader manufactured by LEUTZE in use RU
the barcode could not be read
912017 EC U1 BCREADEREXIST
Unables/Enables the event messages of the BCread
and BCTwinRead events.
0: No BCread and BCTwinRead events send
1: BCread and BCTwinRead events send (default)
GEM-Kernel
1002001 DV A GEMEVENTTEXT.
The equipment will set this string to contain a
description of the most recent event. The Host can
include this variable in any event report it defines.
Communication Model
1002002 EC U1 INITCOMMSTATE.
Initial (power-up) Communications State.
0 = Disabled
1 = Enabled
1002003 EC U2 ESTABLISHCOMMUNICATIONSTIMER.
Time in seconds of how long the equipment will pause
after an unsuccessful Connect Request before
GEM for SIPLACE V5.01
Page 158 of 252 ©Siemens AG, all rights reserved
9,' &ODVV )RUPDW 1DPHDQG'HVFULSWLRQ
sending another. Valid values are 0-32000.s
1002004 EC U1 CONFIGCONNECT.
An EC which controls which SECS message this
Equipment will use for Connect Request.
0 = S1F1
1 = S1F65
2 = S1F13
Control State Model
1002005 EC U1 INITCONTROLSTATE.
Initial (power-up) control superstate.
1 = Off-Line
2 = On-Line
1002006 SV U1 CONTROLSTATE.
The current Control State.
1 = Off-Line/Equipment Off-Line
2 = Off-Line/Attempt On-Line
3 = Off-Line/Host Off-Line
4 = On-Line/Local
5 = On-Line/Remote
1002007 SV U1 PREVIOUSCONTROLSTATE.
The Control State in effect before the most recent
transition to the current Control State.
1 = Off-Line/Equipment Off-Line
2 = Off-Line/Attempt On-Line
3 = Off-Line/Host Off-Line
4 = On-Line/Local
5 = On-Line/Remote
1002008 EC U1 ONLINEFAILED.
The default Control State transition when Attempt On-
Line fails.
1 = Equipment Off-Line
3 = Host Off-Line
1002009 EC U1 ONLINESUBSTATE.
The default (power-up) online substate of the Control
State Model.
4 = Local
5 = Remote
1002010 EC U1 OFFLINESUBSTATE.
The default (power-up) offline substate of the Control
State Model.
GEM for SIPLACE V5.01
©Siemens AG, all rights reserved page 159 of 252
9,' &ODVV )RUPDW 1DPHDQG'HVFULSWLRQ
1 = Equipment Off-Line
2 = Attempt On-Line
3 = Host Off-Line
1002056 SV A OPERATORCMDINRMOTESTATE
The last command issued by the Operator while the
Control state is „Remote“.
An empty text indicates that there was no operator
command in remote state since the last start of the
SIPLACE.
1002057 SV U1 CONTROLMODE
The actual control mode at the SIPLCAE. This SV
indicates which software system is allowed to
download placement programs.
1 = none
2 = the „GEM-Host“
3 = the line computer (LCU)
Process State Model
1002011 SV U1 PROCESSSTATE.
The current Process State.
0 = Machine Initialization
1 = Single Function
2 = Processing
1002012 SV U1 PREVIOUSPROCESSSTATE.
The Process State in effect before the most recent
transition to the current Process State.
0 = Machine initialization
1 = Single Function
2 = Processing
Alarm Management
1002013 SV U4 ALARMID.
The ALID of the most recent Alarm transition.
1002014 SV U1 ALARMSTATE.
The Alarm State now in effect for the most recently
transitioned alarm.
0 = Alarm transitioned OFF
1 = Alarm transitioned ON
1002015 SV U4 ALARMSERIAL.
The sequence number of the most recent alarm
change (going on or going off). This number starts at
zero at power-up and increments by one for each
alarm transition which occurs.
1002016 DV A[0-40] ALARMTEXT.
