GEM for SIPLACE V5.01
©Siemens AG, all rights reserved page 161 of 252
9,' &ODVV )RUPDW 1DPHDQG'HVFULSWLRQ
cc = centiseconds
1002023 SV A TIME.
The Equipment's current date and time. Format is
described in the variable GEMTIMEFORMAT (VID
1002065). It may be either
YYYYMMDDhhmmsscc OR YYMMDDhhmmss
YY(YY) = year
MM = month
DD = day
hh = hours
mm = minutes
ss = seconds
(cc = centiseconds)
Process Program Management
1002024 DV A PPCHANGENAME.
PPID of the Process Program most recently created,
changed, or deleted.
1002025 DV U1 PPCHANGESTATUS.
The action (create, change, delete) taken on a
Process Program
1 = Created
2 = Changed
3 = Deleted
1002026 SV A PPEXECNAME.
The PPID of the currently selected Process Program.
1002027 SV A CURRENTSETUP
Name of current setup loaded in machine
An empty text indicates an error.
1002028 SV A CURRENTPLACEPROGRAM
Name of current placement program loaded in
machine
An empty text indicates an error.
Remote Commands
1002029 SV A PREVIOUSCOMMAND.
The name of the most recent command.
Terminal Service
1002034 EC U1 WBITS10.
An EC which controls the W-Bit setting used when
GEM for SIPLACE V5.01
Page 162 of 252 ©Siemens AG, all rights reserved
9,' &ODVV )RUPDW 1DPHDQG'HVFULSWLRQ
sending S10F1.
0 = W-Bit not set
1 = W-Bit set
Data Collection
1002030 SV U4 PREVIOUSCEID.
The CEID of the most recent Collection event which
has occurred.
1002031 EC BOOL RPTYPE.
This EC controls some aspects of the format of Event
Reports sent by this Equipment.
FALSE = Normal Event Reports
TRUE = Annotated Event Reports
1002032 EC U1 CONFIGEVENTS.
An EC which controls some aspects of the Event
Reports sent by this Equipment.
0 = S6F9 or S6F3
1 = S6F11 or S6F13
1002033 EC U1 WBITS6.
An EC which controls the W-Bit setting used when
sending stream six messages (events, trace)
0 = W-Bit not set
1 = W-Bit set
1002035 SV L EVENTSENABLED.
A list of all Events which are currently enabled.
Format as follows:
/
8&(,'!

!
1002036 DV U4 ECIDCHANGE.
The VID of the Equipment Constant most recently
changed by the Operator.
Spooling
1002037 EC U4 MAXSPOOLTRANSMIT.
The maximum number of spooled messages the
equipment will send each time the Host reads the
spool. A setting of zero indicates that all spooled
messages should be sent. Refer to the description of
S6F23 in the "SECS Message Detail" section for
further information.
1002038 SV U4 SPOOLCOUNTACTUAL.
A count of the number of messages actually present
on the spool disk, adjusted for any messages which
GEM for SIPLACE V5.01
©Siemens AG, all rights reserved page 163 of 252
9,' &ODVV )RUPDW 1DPHDQG'HVFULSWLRQ
have been overwritten or otherwise discarded.
1002039 SV U4 SPOOLCOUNTTOTAL.
A count of the number of messages the equipment
attempted to write to the spool disk. This number
includes messages actually present on the spool disk,
and also any messages which may have been
overwritten or otherwise discarded.
1002040 SV A[16] SPOOLFULLTIME.
The date and time at which the spool file became full.
Format is: YYYYMMDDhhmmsscc. See description
of CLOCK variable above for format details.
1002041 SV U1 SPOOLLOADSUBSTATE.
The current state within the SPOOL LOAD super-
state.
6 = Spool Not Full
7 = Spool Full
1002042 SV A[16] SPOOLSTARTTIME.
The date and time at which the first message was
written to the current spool file. Format is:
YYYYMMDDhhmmsscc.
See description of CLOCK variable above for format
details.
1002043 SV U1 SPOOLSTATE.
The current spool state within the POWER ON super-
state.
2 = Spool Inactive
1 = Spool Active
1002044 SV U1 SPOOLUNLOADSUBSTATE.
The current spool state within the SPOOL UNLOAD
super-state.
3 = Purge Spool
4 = Transmit Spool
5 = No Spool
1002045 EC U1 CONFIGSPOOL.
This EC determines whether spooling is enabled or
disabled for this Equipment.
0 = Disabled
1 = Enabled
1002046 EC BOOL OVERWRITESPOOL.
This EC determines the action to be taken by the
Equipment when the Spool file reaches its capacity.
TRUE = Overwrite Spool
