GEM for SIPLACE V5.01 ©Siemens AG, all rights r eserved page 169 of 252 9,' &ODVV )RUPDW 1DPHDQG'HVFULSWLRQ ,RSHQBQR]]OH!>PEDU@ ,FORVHGBQR]]OH!>PEDU@ ,FXELFBQR]]OH!>PEDU@…
GEM for SIPLACE V5.01
Page 168 of 252 ©Siemens AG, all rights reserved
9,' &ODVV )RUPDW 1DPHDQG'HVFULSWLRQ
!
!
The first element in this list refers to segment 1, the
second to segment 2 and so on. If a segment was not
in use in the last pick up cycle the list for that segment
is left empty.
If the component was picked up from a feeder /HYHO
will contain -1. In the case that the component was
picked up from a tray in the waffle pack changer
7UDFN1XPEHU is set to -1. If both values are not equal
to -1 the component was picked up from a „manual
tray“.
For a detailed description of the data item see „4.2
Data Item Dictionary“.
An empty list indicates an error.
1312005 SV L NOZZLECONF1
Nozzle configuration on revolver head 1. Only valid
after reference run.
/
/
812==/(B7<3(!
,5($/B12==/(B/(1*7+!>PP@
!
!
The nozzle length is measured during the reference
run. It depends on the HEIGHTREVOLVER1 value. So
REAL_NOZZLE_LENGTH is not a absolute but a
relative value.
It is calculated by subtracting the measured distance
between the nozzle and the upper edge of the
transport conveyor from the HEIGHTREVOLVER1
value.
An empty list indicates an error.
For a detailed description of the data item see „4.2
Data Item Dictionary“.
1312006 SV L VACUUMDATAREV1
Vacuum measurements from the last reference run on
revolver head 1. Valid only after reference run.
/
/
GEM for SIPLACE V5.01
©Siemens AG, all rights reserved page 169 of 252
9,' &ODVV )RUPDW 1DPHDQG'HVFULSWLRQ
,RSHQBQR]]OH!>PEDU@
,FORVHGBQR]]OH!>PEDU@
,FXELFBQR]]OH!>PEDU@
,QRWBFXELFBQR]]OH!>PEDU@
,WROBGLUW\BQR]]OH!>PEDU@
,WROBOHDN\ BQR]]OH!>PEDU@
!
!
The first element in this list refers to segment 1, the
second to segment 2, and so on.
tol_dirty_nozzle and tol_leaky_nozzle are currently not
used.
An empty list indicates an error.
For a detailed description of the data item see „4.2
Data Item Dictionary“.
Revolver Head 2 (SIPLACE 80 S 20 only)
1412001 SV I4 HEIGHTREV2
Height of revolver head 2. Only valid after height
reference run. Units are 1/1000 mm. Only valid for
SIPLACE 80S. On a SIPLACE 80F this variable will
contain 0
During the reference run the SIPLACE measures the
distance between the upper edge of the conveyor belt
and the nozzle on segment 1. The
HEIGHTREVOLVER1 is then calculated by subtracting
the length of the nozzle on segment 1 form the
measured value. The nozzle length is defined in the
machine data. So HEIGHTREVOLOR1 is a relative
not an absolute value.
For a detailed description of the data item see „4.2
Data Item Dictionary“.
A value of 0 indicates an error.
1412002 SV L GANTRYINFOREV2
Gantry information for revolver head 2. The data is
automatically reseted when a PCB reaches the center
conveyor.
/
,&RP3LFNHG8S!
,&RPS3ODFHG!
,&RPS/HIW3ODFH!
!
GEM for SIPLACE V5.01
Page 170 of 252 ©Siemens AG, all rights reserved
9,' &ODVV )RUPDW 1DPHDQG'HVFULSWLRQ
ComPickedUp Number of components which
were picked up successfully since
the last PCB reached the center
conveyor
CompPlaced Number of components which
were placed since the last PCB
reached the center conveyor
CompLeft2Place Number of components left to be
placed on the actual PCB
For a detailed description of the data item see „4.2
Data Item Dictionary“.
An empty list indicates an error.
1412003 SV L PLACEINFOREV2
Placement information for revolver head 2. Only valid
for SIPLACE 80S. On a SIPLACE 80F this variable will
contain an empty list.
/
/
8;SRVLWLRQ!>PP@
8<SRVLWLRQ!>PP@
)$QJOH!>GHJUHHV@
8)RUFH,QGH[!
$5HIHUHQFH'HVLJQDWRU!
$&RPSRQHQW1DPH!
83DFNDJH)RUP1XPEHU!
83ODFHPHQW5HVXOW!
,3ODFHPHQW9DFXXP!
,9DFXXP!
8'DWD9DOLG!
,;GHYLDWLRQ!>PP@
,<GHYLDWLRQ!>PP@
)$QJOH!>GHJUHHV@
84XDOLW\!>@
8/HQJWK!>PP@
8:LGWK!>PP@
/
,3LWFKBSHUBOHDGBJURXS!
,3LWFKBSHUBOHDGBJURXS!
