GEM for SIPLACE V5.01
©Siemens AG, all rights reserved page 173 of 252
9,' &ODVV )RUPDW 1DPHDQG'HVFULSWLRQ
/
/
,RSHQBQR]]OH!
,FORVHGBQR]]OH!
,FXELFBQR]]OH!
,QRWBFXELFBQR]]OH!
,WROBGLUW\BQR]]OH!
,WROBOHDN\ BQR]]OH!
!

!
The first element in this list refers to segment 1, the
second to segment 2 and so on.
tol_dirty_nozzle and tol_leaky_nozzle are currently not
used.
For a detailed description of the data item see „4.2
Data Item Dictionary“.
An empty list indicates an error.
IC - Head (SIPLCAE 80 F
4
only)
1512001 SV I4 HEIGHTIC
Height of IC head. Only valid after reference run. Units
are 1/1000 mm. Only valid for SIPLACE 80F. On a
SIPLACE 80S this variable will contain 0.
During the reference run the SIPLACE measures the
distance between the upper edge of the conveyor belt
and the nozzle on the IC-Head. The HEIGHTIC is then
calculated by subtracting the length of the nozzle form
the measured value. The nozzle length is defined in
the machine data. So HEIGHTIC is a relative not an
absolute value.
A value of 0 indicates an error.
1512002 SV L GANTRYINFOIC
Gantry information for IC head . The data is
automatically reset when a PCB reaches the center
conveyor. Only valid for SIPLACE 80F. On a SIPLACE
80S this variable will contain an empty list.
/
,&RP3LFNHG8S!
,&RPS3ODFHG!
,&RPS/HIW3ODFH!
!
GEM for SIPLACE V5.01
Page 174 of 252 ©Siemens AG, all rights reserved
9,' &ODVV )RUPDW 1DPHDQG'HVFULSWLRQ
ComPickedUp Number of components which
were picked up successfully since
the last PCB reached the center
conveyor
CompPlaced Number of components which
were placed since the last PCB
reached the center conveyor
Comp Number of components left TO BE placed on
the actual PCB Number of
components left to be placed on
the actual PCB
An empty list indicates an error.
1512003 SV L NOZZLECONFIC
Nozzle on the IC-Head. Only valid for SIPLACE 80F.
On a SIPLACE 80S this variable will contain an empty
list.
/
812==/(B7<3(!
,5($/B12==/(B/(1*7+!>PP@
!
The nozzle length is measured during the reference
run. It depends on the HEIGHTIC value. So
REAL_NOZZLE_LENGTH is not a absolute but a
relative value.
It is calculated by subtracting the measured distance
between the nozzle and the upper edge of the
conveyor belt from the HEIGHTIC value.
For a detailed description of the data item see „4.2
Data Item Dictionary“.
An empty list indicates an error.
1512004 SV L NOZZLERETURN
Last nozzle returned to the nozzle-changer by the IC-
head. Only valid for SIPLACE 80F. On a SIPLACE
80S this variable will contain an empty list.
/
812==/(B7<3(!
,5($/B12==/(B/(1*7+!>PP@
!
The nozzle length is measured during the reference
run. It depends on the HEIGHTIC value. So
REAL_NOZZLE_LENGTH is not a absolute but a
relative value.
It is calculated by subtracting the measured distance
between the nozzle and the upper edge of the
GEM for SIPLACE V5.01
©Siemens AG, all rights reserved page 175 of 252
9,' &ODVV )RUPDW 1DPHDQG'HVFULSWLRQ
conveyor belt from the HEIGHTIC value.
For a detailed description of the data item see „4.2
Data Item Dictionary“.
An empty list indicates an error.
1512010 SV L VACUUMDATAIC
Vacuum measurements IC-Head. Only valid for
SIPLACE 80F. On a SIPLACE 80S this variable will
contain an empty list.
/
,RSHQBQR]]OH!
,FORVHGBQR]]OH!
,FXELFBQR]]OH!
,QRWBFXELFBQR]]OH!
,WROBGLUW\BQR]]OH!
,WROBOHDN\ BQR]]OH!
!
tol_dirty_nozzle and tol_leaky_nozzle are currently not
used.
For a detailed description of the data item see „4.2
Data Item Dictionary“.
An empty list indicates an error.
1512013 SV L COPLANARITYDATAIC
Result of last coplanarity measurement. Only valid for
SIPLACE 80F. On a SIPLACE 80S this variable will
contain an empty list.
/
$&RPSRQHQW1DPH!
83DFNDJH)RUP1XPEHU!
85HVXOW!0:Ok; 1:Error
,0D[/HDG'HY!>PP@
!
The coplanarity module measures the height of all
leads and calculates then a hypothetical plane through
the three highest leads. 0D[/HDG'HY is the greatest
deviation between one lead and this plane.
For a detailed description of the data item see „4.2
Data Item Dictionary“.
An empty list indicates an error.
1512014 SV L PLACEINFOIC
