GEM for SIPLACE V5.01 Page 178 of 252 ©Siemens AG, all rights reserved 9,' &ODVV )RUPDW 1DPHDQG'HVFULSWLRQ Bit 3: If bit is set, the prox imity switch of the adjustm ent width is switched. Bit 4: If bit i…

GEM for SIPLACE V5.01

9,' &ODVV )RUPDW 1DPHDQG'HVFULSWLRQ

[RUWKRJRQDOGHYLDWLRQ

[PD[OHDGGHYLDWLRQ

[PD[EDOOGHYLDWLRQ

For a detailed description of the data item see „4.2

Data Item Dictionary“.

An empty list indicates an error.

1512015 SV L PICKUPINFOIC

Pick-up information for IC-head . Only valid for

SIPLACE 80F. On a SIPLACE 80S this variable will

contain an empty list.

/

$&RPSRQHQW1DPH!

,7UDFN1XPEHU!

8)HHGHU7\SH!

,/HYHO!

,'LYLVLRQ!

80DFKLQH6LGH!

83LFN8S5HVXOW!

,3LFN8S9DFXXP!

,9DFXXP!

If the component was picked up from a feeder /HYHO

will contain -1. In the case that the component was

picked up from a tray in the waffle pack changer

7UDFN1XPEHU is set to -1. If both values are not equal

to -1 the component was picked up from a „manual

tray“.

For a detailed description of the data item see „4.2

Data Item Dictionary“.

An empty list indicates an error.

I / O Ports

2012001 SV U1 INPUTPORTBYTE1

Bit 0: If bit is set, the upper proximity switch of the

lifting table is not switched.

Bit 1: If bit is set, the lower proximity switch of the

lifting table is not switched.

Bit 2: If bit is set, the proximity switch of the

stopper of the parallel conveyer is switched.

GEM for SIPLACE V5.01

9,' &ODVV )RUPDW 1DPHDQG'HVFULSWLRQ

Bit 3: If bit is set, the proximity switch of the

adjustment width is switched.

Bit 4: If bit is set, the adjustment width is at the

limit switch.

Bit 5: If bit is set, the proximity switch of the

stopper is switched.

Bit 6: If bit is set, the software switch high voltage

is off.

Bit 7: If bit is set, the ceramic substrate centering

is open.

A value of -1 indicates an error

2012002 SV U1 INPUTPORTBYTE2

Bit 0: If bit is set, high voltage is on.

Bit 1: If bit is set, the emergency stop button is

down.

Bit 2: If bit is set, the protective covers are open.

Bit 3: If bit is set, the start button was actuated.

Bit 4: If bit is set, the stop button was actuated.

Bit 5: If bit is set, the key switch is not set.

Bit 6: If bit is set, the compress air unit is active.

Bit 7: If bit is set, the axis operation voltage is

active.

A value of -1 indicates an error

2012003 SV U1 INPUTPORTBYTE3

Bit 0: If bit is set, the gantry crash sensor was set

Bit 1: If bit is set, the gantry proximity sensor was

set.

Bit 2: If bit is set, the open proximity switch of the

nozzle changer of gantry 1 is switched.

Bit 3: If bit is set, the close proximity switch of the

nozzle changer of gantry 1 is switched.

Bit 4: If bit is set, the open proximity switch of the

nozzle changer of gantry 2 is switched.

Bit 5: If bit is set, the close proximity switch of the

nozzle changer of gantry 2 is switched.

Bit 6: If bit is set, the center conveyer sensor is

covered.

Bit 7: If bit is set, the center conveyer sensor of

parallel conveyor is covered. A value of -1

indicates an error

2012004 SV U1 INPUTPORTBYTE4

Bit 0: If bit is set, the Interface signal "Request"

to the preceding station is active.

Bit 1: If bit is set, the Interface signal "Sent" to the

GEM for SIPLACE V5.01

9,' &ODVV )RUPDW 1DPHDQG'HVFULSWLRQ

preceding station is active.

Bit 2: If bit is set, the Interface signal

"Permission" to the following station is

active.

Bit 3: If bit is set, the Interface signal "Received"

to the following station is active.

Bit 4: If bit is set, the input conveyor sensor is

covered.

Bit 5: If bit is set, the input conveyor sensor of the

parallel conveyer is covered.

Bit 6: If bit is set, the output conveyor sensor is

covered.

Bit 7: If bit is set, the output conveyor sensor of

the parallel conveyor is covered.

A value of -1 indicates an error

2012005 SV U1 INPUTPORTBYTE5

Bit 0: If bit is set, the upper proximity switch of the

lifting table of the second transport track is

not switched.

Bit 1: If bit is set, the lower proximity switch of the

lifting table of the second transport track is

not switched.

Bit 2: Not used.

Bit 3: If bit is set, the proximity switch of the

adjustment width of the second transport

track is switched.

Bit 4: If bit is set, the adjustment width of the

second transport track is at the limit switch.

Bit 5: Not used.

Bit 6: Not used.

Bit 7: If bit is set, the ceramic substrate centering

of the second transport track is open.

A value of -1 indicates an error

2012006 SV U1 INPUTPORTBYTE6

Bit 0: If bit is set, the Interface signal "Request"

to the preceding station of the second

transport track is active.

Bit 1: If bit is set, the Interface signal "Sent" to the

preceding station of the second transport

track is active.

Bit 2: If bit is set, the Interface signal

"Permission" to the following station is

active.

Bit 3: If bit is set, the Interface signal "Received"

to the following station of the second

transport track is active.
