GEM for SIPLACE V5.01
Page 182 of 252 ©Siemens AG, all rights reserved
9,' &ODVV )RUPDW 1DPHDQG'HVFULSWLRQ
of the second transport track is in fast
mode 2.
A value of -1 indicates an error
2012012 SV U1 OUTPUTPORTBYTE6
Bit 0: The Interface signal "Request" to the
preceding station of the second transport
track is set.
Bit 1: The Interface signal "Sent" to the preceding
station of the second transport track is set.
Bit 2: The Interface signal "Permission" to the
following station of the second transport
track is set.
Bit 3: The Interface signal "Received" to the
following station of the second transport
track is set.
Bit 4: If bit is set, the motor of the width
adjustment of the second transport track is
in fast mode.
Bit 5: If bit is set, the width of the second
transport track is being adjusted smaller.
Bit 6: If bit is set, the width of the second
transport track is being adjusted larger.
Bit 7: Operates the ceramic substrate centering
of the second transport track.
A value of -1 indicates an error
2012013 SV U2 ERRORTYPE
Type of the most recent error
2 Transport
3 Machine error
4 Track error
5 Miscellaneous
A value of 0 indicates an error.
2012014 SV U2 GANRTYONERROR
Gantry associated with the most recent error
A value of 0 indicates an error.
2012015 SV U2 SEGMENTONERROR
Segment number associated with the most recent
error
A value of 0 indicates an error.
2012016 SV U2 TRACKONERROR
Track number associated with the most recent error
GEM for SIPLACE V5.01
©Siemens AG, all rights reserved page 183 of 252
9,' &ODVV )RUPDW 1DPHDQG'HVFULSWLRQ
event
A value of 0 indicates an error.
2012017 SV U2 ERRORINFO1
A value of 0 indicates an error.
2012018 SV U2 ERRORINFO2
A value of 0 indicates an error.
2012019 SV L PICKUPERRORS
Pick-Up Errors. This data item will be reset when a
new Process Program is downloaded to a SIPLACE
machine.
/
/
$&RPSRQHQW1DPH!
,7UDFN1XPEHU!
8)HHGHU7\SH!
,/HYHO!
,'LYLVLRQ!
80DFKLQH6LGH!
8)HHGHU$FFHVVHV3HU3&%!
83LFN8S(UURUV!
82SWLFDO(UURUV!
8&RSODQDULW\(UURUV!
!
!
FeederAccessesPerPCB will be reset when a PCB
reaches the center conveyor.
If the component was picked up from a feeder /HYHO
will contain -1. In the case that the component was
picked up from a tray in the waffle pack changer
7UDFN1XPEHU is set to -1. If both values are not equal
to -1 the component was picked up from a „manual
tray“.
For a detailed description of the data item see „4.2
Data Item Dictionary“.
An empty list indicates an error.
2012020 SV A PICKUPDATARESETPOINT
GEM for SIPLACE V5.01
Page 184 of 252 ©Siemens AG, all rights reserved
9,' &ODVV )RUPDW 1DPHDQG'HVFULSWLRQ
Date and time when the „Pick-Up Error“ data item was
reset.
An empty text indicates an error.
2012021 SV L GANTRYHEADCONFIG
/
/
,*DQWU\*URXS,'(not used)
/
/
,*DQWU\ ,'!
,7\SH2I*DQWU\!
/
/
,+HDG,'!
,+($'7<3(!
!
!
!
!
!
HEADTYPE:
5 = Revolverhead with 12 nozzles
6 = Revolverhead with 6 nozzles
7 = IC Head
On a SIPLACE S20 the first gantry in the list is the left
one in transport direction, the second is the right one.
The SIPLACE 80F4 has 2 Head mounted on gantry
one. Head 1 is the one on the left side.
For a detailed description of the data item see „4.2
Data Item Dictionary“.
2012022 DV U1 MACHINESIDE
0 = right side in transport direction
1 = left side in transport direction
99 = error ocurred
Only valid in use with the Collection Events
<ComponentBCread> and <PickupError>
2012023 DV I2 TRACKNUMBER
