GEM for SIPLACE V5.01 ©Siemens AG, all rights r eserved page 185 of 252 9,' &ODVV )RUPDW 1DPHDQG'HVFULSWLRQ Only valid in use with the Collection Events <ComponentBCr ead> and <Pick upError > …
GEM for SIPLACE V5.01
Page 184 of 252 ©Siemens AG, all rights reserved
9,' &ODVV )RUPDW 1DPHDQG'HVFULSWLRQ
Date and time when the „Pick-Up Error“ data item was
reset.
An empty text indicates an error.
2012021 SV L GANTRYHEADCONFIG
/
/
,*DQWU\*URXS,'(not used)
/
/
,*DQWU\ ,'!
,7\SH2I*DQWU\!
/
/
,+HDG,'!
,+($'7<3(!
!
!
!
!
!
HEADTYPE:
5 = Revolverhead with 12 nozzles
6 = Revolverhead with 6 nozzles
7 = IC Head
On a SIPLACE S20 the first gantry in the list is the left
one in transport direction, the second is the right one.
The SIPLACE 80F4 has 2 Head mounted on gantry
one. Head 1 is the one on the left side.
For a detailed description of the data item see „4.2
Data Item Dictionary“.
2012022 DV U1 MACHINESIDE
0 = right side in transport direction
1 = left side in transport direction
99 = error ocurred
Only valid in use with the Collection Events
<ComponentBCread> and <PickupError>
2012023 DV I2 TRACKNUMBER
GEM for SIPLACE V5.01
©Siemens AG, all rights reserved page 185 of 252
9,' &ODVV )RUPDW 1DPHDQG'HVFULSWLRQ
Only valid in use with the Collection Events
<ComponentBCread> and <PickupError>
For a detailed description of the data item see „4.2
Data Item Dictionary“.
2012024 DV I2 DIVISION
Only valid in use with the Collection Events
<ComponentBCread> and <PickupError>
For a detailed description of the data item see „4.2
Data Item Dictionary“.
2012025 DV I2 LEVEL
Only valid in use with the Collection Events
<ComponentBCread> and <PickupError>
For a detailed description of the data item see „4.2
Data Item Dictionary“.
2012026 DV U1 SEGMENT
Only valid in use with the Collection Events
<PickupError> and <PlaceError>
For a detailed description of the data item see „4.2
Data Item Dictionary“.
2012027 DV A COMPONENTNAME
Only valid in use with the Collection Events
<PickupError> and <PlaceError>
For a detailed description of the data item see „4.2
Data Item Dictionary“.
2012028 DV U2 GANTRYID
Only valid in use with the Collection Events
<PickupError> and <PlaceError>
For a detailed description of the data item see „4.2
Data Item Dictionary“.
2012029 DV U2 GANTRYGROUPID
Only valid in use with the Collection Events
<PickupError> and <PlaceError>
For a detailed description of the data item see „4.2
Data Item Dictionary“.
2012030 DV U2 HEADID
Only valid in use with the Collection Events
<PickupError> and <PlaceError>
For a detailed description of the data item see „4.2
Data Item Dictionary“.
2012031 DV A REFERENCEDESIGNATOR
Only valid in use with the Collection Event
<PlaceError>
For a detailed description of the data item see „4.2
Data Item Dictionary“.
GEM for SIPLACE V5.01
Page 186 of 252 ©Siemens AG, all rights reserved
9,' &ODVV )RUPDW 1DPHDQG'HVFULSWLRQ
2012032 DV U2 PACKAGEFORMNUMBER
Only valid in use with the Collection Event
<PlaceError>
For a detailed description of the data item see „4.2
Data Item Dictionary“.
2012033 DV U2 PLACEERRORDESCRIPTION
Only valid in use with the Collection Event
<PlaceError>
For a detailed description of the data item see „4.2
Data Item Dictionary“.
