GEM for SIPLACE V5.01
Page 186 of 252 ©Siemens AG, all rights reserved
9,' &ODVV )RUPDW 1DPHDQG'HVFULSWLRQ
2012032 DV U2 PACKAGEFORMNUMBER
Only valid in use with the Collection Event
<PlaceError>
For a detailed description of the data item see „4.2
Data Item Dictionary“.
2012033 DV U2 PLACEERRORDESCRIPTION
Only valid in use with the Collection Event
<PlaceError>
For a detailed description of the data item see „4.2
Data Item Dictionary“.
GEM for SIPLACE V5.01
©Siemens AG, all rights reserved page 187 of 252
3UHGHILQHG5HSRUWV
537,' 1DPH 9,'V
0 Clock 1002022<CLOCK>
1 Clock and Name 1002022<CLOCK>, 1002001<GEMEVENTTEXT>
2 PlaceInfoSP 1002022<CLOCK>, 1002001<GEMEVENTTEXT>,
1312002<GANTRYINFOREV1>,
1412002<GANTRYINFOREV2>
3 PlaceInfoIC 1002022<CLOCK>, 1002001<GEMEVENTTEXT>,
1312002<GANTRYINFOREV1>,
1512002<GANTRYINFOIC>
4 Transport 1002022<CLOCK>, 1002001<GEMEVENTTEXT>,
612007<TRANSPORTWIDTH>
5 PlaceHead1 1002022<CLOCK>, 1002001<GEMEVENTTEXT>,
1312003< PLACEINFOREV1
>
6 PlaceHead2 1002022<CLOCK>, 1002001<GEMEVENTTEXT>,
1412003< PLACEINFOREV2>
7 PlaceIC 1002022<CLOCK>, 1002001<GEMEVENTTEXT>,
1512014< PLACEINFOIC>
8 PickHead1 1002022<CLOCK>, 1002001<GEMEVENTTEXT>,
1312004< PICKUPINFOREV1>
9 PickHead2 1002022<CLOCK>, 1002001<GEMEVENTTEXT>,
1412004< PICKUPINFOREV2>
10 PickIC 1002022<CLOCK>, 1002001<GEMEVENTTEXT>,
1512015< PICKUPINFOIC>
11 not used
12 Coplan 1002022<CLOCK>, 1002001<GEMEVENTTEXT>,
1512013< COPLANARITYDATAIC>
13 Fiducial 1002022<CLOCK>, 1002001<GEMEVENTTEXT>,
412002< FIDUCIALDATA>
14 Nozzle1 1002022<CLOCK>, 1002001<GEMEVENTTEXT>,
1312001< HEIGHTREV1>,
1312005<NOZZLECONF1>
15 Nozzle2 1002022<CLOCK>, 1002001<GEMEVENTTEXT>,
1412001<HEIGHTREV2>,
1412005<NOZZLECONF2>
16 ICnozzleRet 1002022<CLOCK>, 1002001<GEMEVENTTEXT>,
1512004< NOZZLERETURN>
17 ICnozzlePick 1002022<CLOCK>, 1002001<GEMEVENTTEXT>,
1512003< NOZZLECONFIC>
18 InvetoryWPC 1002022<CLOCK>, 1002001<GEMEVENTTEXT>,
812001<INVENTARYWPC>
19 not used
20 not used
21 RefRunVac1 1002022<CLOCK>, 1002001<GEMEVENTTEXT>,
1312006< VACUUMDATAREV1>
GEM for SIPLACE V5.01
Page 188 of 252 ©Siemens AG, all rights reserved
537,' 1DPH 9,'V
22 RefRunVac2 1002022<CLOCK>, 1002001<GEMEVENTTEXT>,
1412006 <VACUUMDATAREV2>
23 TableSW 1002022<CLOCK>, 1002001<GEMEVENTTEXT>,
1002054< SOFTWAREREVTABLE>
24 Barcode 1002022<CLOCK>, 1002001<GEMEVENTTEXT>,
912002< BCININPUTCONVEYOR>,
912005<PCBSIDEININPUTCONVEYOR>
25 FidTaugh 1002022<CLOCK>, 1002001<GEMEVENTTEXT>,
412001< TAUGHTFIDUCIAL>
26 PFmodified 1002022<CLOCK>, 1002001<GEMEVENTTEXT>,
512001< HEIGHTIC>
27 BeBarcode 1002022<CLOCK>, 1002001<GEMEVENTTEXT>,
912003<COMPONENTBARCODE>,
912004<WAYOFINPUTCOMPONENTBARCODE>
, 2012022<MACHINESIDE>,
2012023<TRACKNUMBER>,
2012024<DIVISION>, 2012025<LEVEL
>
28 PickupError 1002022<CLOCK>, 1002001<GEMEVENTTEXT>,
2012026<SEGMENT>,
2012027<COMPONENTNAME>,
2012022<MASCHINESIDE>,
2012023<TRACKNUMBER>,
2012024<DIVISION>, 2012025<LEVEL>,
2012028<GANTRYID>,
2012029<GANTRYGROUPID>,
2012030<HEADID>
29 PlaceError 1002022<CLOCK>, 1002001<GEMEVENTTEXT>,
2012026<SEGMENT>,
2012031<REFERENCEDESIGNATOR>,
2012028<GANTRYID>,
2012029<GANTRYGROUPID>,
2012030<HEADID>
2012032<PACKAGEFORMNUMBER>,
2012033<PLACEERRORDESCRIPTION>
30 BarcodeTwin 1002001<GEMEVENTTEXT>, 1002022<CLOCK>,
912012<BCINTWININPUTCONVEYOR>,
912015<PCBSIDEINTWININPUTCONVEYOR>
