GEM for SIPLACE V5.01
Page 190 of 252 ©Siemens AG, all rights reserved
121027 FM_NF_DEFAULT NF: unexpected input* 1
121028 FM_EF_SWF SF: unexpected input: * 1
121029 FM_EF_MC_NOK SF: answer from wrong MC* 1
121030 FM_EF_GLK_NOK SF: global communication not ok* 1
121031 FM_GK_MA_DAT_LOKAL GK: Error in local machine data* 1
121032 FM_GK_MA_DAT GK: Error in machine data* 1
121033 FM_GK_RU_DAT GK: Error in set-up data* 1
121034 FM_GK_NU_DAT GK: Error in cluster data* 1
121035 FM_GK_MK_DAT GK: Error in fiducial data* 1
121036 FM_GK_GF_DAT GK: Error in package form data* 1
121037 FM_AKT_NO_ALOC AKT: Error during system call ALOC* 1
121038 FM_AKT_INPUT_NOK AKT: Incorrect input* 1
121039 FM_AKT_DA_SCHNITT_NOK AKT: Wrong data from data
preparation*
1
121040 FM_AKT_WRITE File AKTUELL.MA cannot be stored* 1
111041 FM_RIO__11_F0 Communication with vision system
faulty (Errorcode -11) *
1
111042 FM_RIO__10_F1 Communication with vision system
faulty (Errorcode -10) *
1
111043 FM_RIO__9_F2 Communication with vision system
faulty (Errorcode -9) *
1
111044 FM_RIO__8_F3 Communication with vision system
faulty (Errorcode -8) *
1
111045 FM_RIO__7_F4 Communication with vision system
faulty (Errorcode -7) *
1
111046 FM_RIO__6_F5 Communication with vision system
faulty (Errorcode -6) *
1
111047 FM_RIO__5_F6 Communication with vision system
faulty (Errorcode -5) *
1
111048 FM_RIO__4_F7 Communication with vision system
faulty (Errorcode -4) *
1
111049 FM_RIO__3_F8 Communication with vision system
faulty (Errorcode -3) *
1
111050 FM_RIO__2_F9 Communication with vision system
faulty (Errorcode -2) *
1
111051 FM_RIO__1_FA Communication with vision system
faulty (Errorcode -1) *
1
111052 FM_RIO_0_FB Communication with vision system
faulty (Errorcode 0) *
1
111053 FM_RIO_1_FC Communication with vision system
faulty (Errorcode 1) *
1
111054 FM_RIO_2_FD undefined error number from vision
system (Errorcode 2) *
1
111055 GEM_UNDEF_FEHLER error not defined for GEM interface 1
GEM for SIPLACE V5.01
©Siemens AG, all rights reserved page 191 of 252
111056 FM_SW_PIP_OFF Reading of Nozzle offset not possible* 1
111057 FM_SYS_INIT Initialization of software resources not
correct*
1
111058 FM_ZENTR_ART Incorrect centering device setting for
component concerned*
1
111059 FM_GEM_UNBEK_MELD Unknown message from SC to GEM
computer*
1
111060 FM_GLK_SND_OVL Overflow of send queue of GEM-GLC* 1
111061 FM_GLK_NO_MEM No storage space for GEM-GLC* 1
111062 FM_GLK_INI_APL Error upon initialization of GEM-GLC* 1
111063 FM_GLK_UNBEK_FHL Unknown error number of GEM-GLC* 1
111064 FM_PDV_DAT_RES Error upon reserving data for GEM* 1
111065 FM_PDV_NO_DATA GEM datum not found* 1
111066 FM_PDV_UNBEK_FHL Unknown error number from GEM
process data management*
1
111067 FM_ACHS_MA ACHS.MA file missing or faulty* 1
111068 FM_ACHS_STD_MA ACHS_STD.MA file missing or faulty* 1
111069 FM_ACHS_VER_MA ACHS_VER.MA file missing or faulty* 1
111070 FM_KRAFT_MA KRAFT.MA file missing or faulty* 1
111071 FM_REAL_MA REAL.MA file missing or faulty* 1
111072 FM_FLUX_MA FLUX.MA file missing or faulty* 1
111073 FM_MAPP_11_MA MAPP_11.MA file missing or faulty* 1
111074 FM_MAPP_12_MA MAPP_12.MA file missing or faulty* 1
111075 FM_MAPP_21_MA MAPP_21.MA file missing or faulty* 1
111076 FM_MAPP_22_MA MAPP_22.MA file missing or faulty* 1
111077 FM_MAPPSTEU_MA MAPPSTEU.MA file missing or faulty* 1
111078 FM_CONFIG_MA KONFIG.MA file missing or faulty* 1
111079 FM_X_PROG_SPUR X-pick-up position out of travel range* 1
111080 FM_Y_PROG_SPUR Y-pick-up position out of travel range* 1
111081 FM_SONST_SPURLEER Track empty due to exceeding the
travel range*
1
111082 FM_SV_SW_FEHLER Error in placement sequence
software*
1
111083 FM_BEST_EBENE Placement sequence error in PCB
data*
1
111084 FM_SV_CONFIG file KONFIG.MA incorrect* 1
111085 FM_SW_VAK_SCAN_MA file SCANPARA.MA incorrect or
missing*
1
111086 FM_SW_VAKUUM_MA file VAKUUM.MA incorrect or missing* 1
111087 FM_ABBRUCH SITEST: action aborted* 1
111088 FM_SW_KRIWEGE_MA KRIWEGE.MA file not available or 1
GEM for SIPLACE V5.01
Page 192 of 252 ©Siemens AG, all rights reserved
corrupted*
111089 FM_HOEH_PIP_ZUVIEL Unknown nozzle at segment, none
specified in configuration*
1
111090 FM_BLASDRUCK_ZU_GERING RV head: Air kiss pressure during
placement too low*
1
111091 FM_BLASDRUCK_ZU_HOCH RV head: Air kiss pressure during
placement too high*
1
111092 FM_GK_SR_STAND_ALONE Communication problem with LC,
station switched to 'Stand alone'*
1
111093 FM_MAP_MESSD_FEHLT MP_MESS.DAT mapping file not
available*
1
111094 FM_MAP_MESSD_NR_FALSCH Faulty number in MP_MESS.DAT
mapping file*
1
111095 FM_MAP_MESSD_INDEX Bad access to MP_MESS.DAT file* 1
111096 FM_MAP_DAT_KOMM Task mapping data: communications
error*
1
* Depending on the collection event, some of the status variables <ERRORTYPE>,
<GANTRYONERROR>, <SEGMENTONERROR>, <TRACKONERROR>,
<ERRORINFO1> and <ERRORINFO2> will be updated at each of these software
collection events.
1R]]OH&KDQJH U
CEID Name Description
211001 FM_PW_IC_OPTION IC head nozzle-changer option not
set*
1
211002 FM_PW_IC_PIPTYP Nozzle type not available* 1
211003 FM_PW_IC_RUESTUNG Nozzle type not in IC head nozzle-
changer set-up*
1
211004 FM_PW_IC_PIP_VORH Nozzle available on IC head* 1
211005 FM_PW_IC_ABW_D_ABH Deviation in d axis rotation at IC head
nozzle pick-up*
1
211006 FM_PW_IC_ABW_D_ABL Deviation in d axis rotation at IC head
nozzle return*
1
211007 FM_PW_IC_Z_SOLLPO_UEB_
ABH
Required Z-axis position exceeded
during IC nozzle pick-up*
1
211008 FM_PW_IC_Z_SOLLPO_N_ER
_ABH
Required Z-axis position exceeded
during IC nozzle pick-up*
1
211009 FM_PW_IC_Z_SOLLPO_UEB_
ABL
Required Z-axis position exceeded at
IC nozzle return*
1
211010 FM_PW_IC_Z_SOLLPO_N_ER
_ABL
Required Z-axis position not reached
at IC nozzle return*
1
211011 FM_PW_IC_NO_PIP Nozzle not available at nozzle changer
IC head*
1
211012 FM_PW_IC_UMRUESTEN Modify nozzle changer IC head* 1
