GEM for SIPLACE V5.01
©Siemens AG, all rights reserved page 195 of 252
CEID Name Description
311022 FM_CRASH Gantry distance insufficient. Protective
system reacted*
1
311023 FM_X_TIMEOUT 59 X axis: does not reach required
position*
1
311024 FM_Y_TIMEOUT 60 Y axis: does not reach required
position*
1
311025 FM_S_TIMEOUT 38 S axis: does not reach required
position*
1
311026 FM_Z_SP_TIMEOUT 61 SP/Z axis: does not reach required
position*
1
311027 FM_D_TIMEOUT 8 SP/D axis: does not reach required
position*
1
311028 FM_Z_IC_TIMEOUT IC/Z axis: does not reach required
position*
1
311029 FM_D_IC_TIMEOUT IC/D axis: does not reach required
position*
1
311030 FM_X_TIMEOUT_PROXIMITY
SWITCH
Undefined 1
311031 FM_Y_TIMEOUT_PROXIMITY
SWITCH
Undefined 1
311032 FM_S_TIMEOUT_PROXIMITY
SWITCH
Undefined 1
311033 FM_Z_SP_TIMEOUT_PROXIMI
TY SWITCH
20 SP/Z axis: top Proximity switch
does not respond*
1
311034 FM_D_TIMEOUT_PROXIMITY
SWITCH
Undefined 1
311035 FM_Z_IC_TIMEOUT_PROXIMIT
Y SWITCH
IC/Z axis: top Proximity switch does
not respond*
1
311036 FM_D_IC_TIMEOUT_PROXIMIT
Y SWITCH
Undefined 1
311037 FM_X_PROXIMITY
SWITCH_NICHT_FREI
Undefined 1
311038 FM_Y_PROXIMITY
SWITCH_NICHT_FREI
Undefined 1
311039 FM_S_PROXIMITY
SWITCH_NICHT_FREI
Undefined 1
311040 FM_Z_SP_PROXIMITY
SWITCH_NICHT_FREI
SP/Z axis: top Proximity switch is not
released*
1
311041 FM_D_PROXIMITY
SWITCH_NICHT_FREI
Undefined 1
311042 FM_Z_IC_PROXIMITY
SWITCH_NICHT_FREI
IC/Z axis: top Proximity switch is not
released*
1
311043 FM_D_IC_PROXIMITY
SWITCH_NICHT_FREI
Undefined 1
311044 FM_X_POS_PROXIMITY X axis: Proximity switch for position 1
GEM for SIPLACE V5.01
Page 196 of 252 ©Siemens AG, all rights reserved
CEID Name Description
SWITCH monitoring is off*
311045 FM_Y_POS_PROXIMITY
SWITCH
Y axis: Proximity switch for position
monitoring is off*
1
311046 FM_S_POS_PROXIMITY
SWITCH
S axis: Proximity switch for position
monitoring is off*
1
311047 FM_Z_SP_POS_PROXIMITY
SWITCH
SP/Z axis: Proximity switch for
position monitoring is off*
1
311048 FM_D_POS_PROXIMITY
SWITCH
SP/D axis: Proximity switch for
position monitoring is off*
1
311049 FM_Z_IC_POS_PROXIMITY
SWITCH
IC/Z axis: Proximity switch for position
monitoring is off*
1
311050 FM_D_IC_POS_PROXIMITY
SWITCH
IC/D axis: Proximity switch for position
monitoring is off*
1
311051 FM_X_ERROR_BIT X axis: Error bit set* 1
311052 FM_Y_ERROR_BIT Y axis: Error bit set* 1
311053 FM_S_ERROR_BIT S axis: Error bit set* 1
311054 FM_Z_SP_ERROR_BIT SP/Z axis: Error bit set* 1
311055 FM_D_ERROR_BIT SP/D axis: Error bit set* 1
311056 FM_Z_IC_ERROR_BIT IC/Z axis: Error bit set* 1
311057 FM_D_IC_ERROR_BIT IC/D axis: Error bit set* 1
311058 FM_X_WARTE_DAIN X axis: No DAIN acknowledgment* 1
311059 FM_Y_WARTE_DAIN Y axis: No DAIN acknowledgment* 1
311060 FM_S_WARTE_DAIN S axis: No DAIN acknowledgment* 1
311061 FM_Z_SP_WARTE_DAIN SP/Z axis: No DAIN acknowledgment* 1
311062 FM_D_WARTE_DAIN SP/D axis : No DAIN
acknowlegdment*
1
311063 FM_Z_IC_WARTE_DAIN IC/Z axis: No DAIN acknowledgment* 1
311064 FM_D_IC_WARTE_DAIN IC/D axis: No DAIN acknowledgment* 1
311086 FM_X_AK_UNG X axis: command currently invalid* 1
311087 FM_Y_AK_UNG Y axis: command currently invalid* 1
311088 FM_S_AK_UNG S axis: command currently invalid* 1
311089 FM_Z_SP_AK_UNG SP/Z axis: command currently invalid* 1
311090 FM_D_AK_UNG SP/D axis: command currently invalid* 1
311091 FM_Z_IC_AK_UNG IC/Z axis: command currently invalid* 1
311092 FM_D_IC_AK_UNG IC/D axis: command currently invalid* 1
311093 FM_X_AK_UNDEF X axis: command not defined* 1
311094 FM_Y_AK_UNDEF Y axis: command not defined* 1
311095 FM_S_AK_UNDEF S axis: command not defined* 1
311096 FM_Z_SP_AK_UNDEF SP/Z axis: command not defined* 1
311097 FM_D_AK_UNDEF SP/D axis: command not defined* 1
GEM for SIPLACE V5.01
©Siemens AG, all rights reserved page 197 of 252
CEID Name Description
311098 FM_Z_IC_AK_UNDEF IC/Z axis: command not defined* 1
311099 FM_D_IC_AK_UNDEF IC/D axis: command not defined* 1
311100 FM_X_POSART_UNDEF X axis: positioning type not defined* 1
311101 FM_Y_POSART_UNDEF Y axis: positioning type not defined* 1
311102 FM_S_POSART_UNDEF S axis: positioning type not defined* 1
311103 FM_Z_SP_POSART_UNDEF SP/Z axis: positioning type not
defined*
1
311104 FM_D_POSART_UNDEF SP/D axis: positioning type not
defined*
1
311105 FM_Z_IC_POSART_UNDEF IC/Z axis: positioning type not defined* 1
311106 FM_D_IC_POSART_UNDEF IC/D axis: positioning type not
defined*
1
311107 FM_X_VERFAHRBEREICH X axis: destination position outside
travel range*
1
311108 FM_Y_VERFAHRBEREICH Y axis: destination position outside
travel range*
1
311109 FM_S_VERFAHRBEREICH S axis: destination position outside
travel range*
1
311110 FM_Z_SP_VERFAHRBEREICH SP/Z axis: destination position outside
travel range*
1
311111 FM_D_VERFAHRBEREICH SP/D axis: destination position outside
travel range*
1
311112 FM_Z_IC_VERFAHRBEREICH IC/Z axis: destination position outside
travel range*
1
311113 FM_D_IC_VERFAHRBEREICH IC/D axis: destination position outside
travel range*
1
311114 FM_X_REFMODE_UNDEF X axis: reference point type not
defined*
1
311115 FM_Y_REFMODE_UNDEF X axis: reference point type not
defined*
1
311116 FM_S_REFMODE_UNDEF S axis: reference point type not
defined*
1
311117 FM_Z_SP_REFMODE_UNDEF SP/Z axis: reference point type not
defined*
1
311118 FM_D_REFMODE_UNDEF SP/D axis: reference point type not
defined*
1
311119 FM_Z_IC_REFMODE_UNDEF IC/Z axis: reference point type not
defined*
1
311120 FM_D_IC_REFMODE_UNDEF IC/D axis: reference point type not
defined*
1
311121 FM_X_ZAEHLFEHLER X axis: counting error* 1
311122 FM_Y_ZAEHLFEHLER Y axis: counting error* 1
311123 FM_S_ZAEHLFEHLER S axis: counting error* 1
