GEM for SIPLACE V5.01
Page 198 of 252 ©Siemens AG, all rights reserved
CEID Name Description
311124 FM_Z_SP_ZAEHLFEHLER SP/Z axis: counting error* 1
311125 FM_D_ZAEHLFEHLER SP/D axis: counting error* 1
311126 FM_Z_IC_ZAEHLFEHLER IC/Z axis: counting error* 1
311127 FM_D_IC_ZAEHLFEHLER IC/D axis: counting error* 1
311128 FM_X_REF_NICHT_GEF X axis: correct zero pulse not found* 1
311129 FM_Y_REF_NICHT_GEF Y axis: correct zero pulse not found* 1
311130 FM_S_REF_NICHT_GEF S axis: correct zero pulse not found* 1
311131 FM_Z_SP_REF_NICHT_GEF SP/Z axis: correct zero pulse not
found*
1
311132 FM_D_REF_NICHT_GEF SP/D axis: correct zero pulse not
found*
1
311133 FM_Z_IC_REF_NICHT_GEF IC/Z axis: correct zero pulse not
found*
1
311134 FM_D_IC_REF_NICHT_GEF IC/D axis: correct zero pulse not
found*
1
311135 FM_X_SERVO_FREI 63 X axis: disabled* 1
311136 FM_Y_SERVO_FREI 64 Y axis: disabled* 1
311137 FM_S_SERVO_FREI 67 S axis: disabled* 1
311138 FM_Z_SP_SERVO_FREI 68 SP/Z axis: disabled* 1
311139 FM_D_SERVO_FREI 66 SP/D axis: disabled* 1
311141 FM_X_DECODE X axis: error during command
decoding*
1
311142 FM_Y_DECODE Y axis: error during command
decoding*
1
311143 FM_S_DECODE S axis: error during command
decoding*
1
311144 FM_Z_SP_DECODE SP/Z axis: error during command
decoding*
1
311145 FM_D_DECODE SP/D axis: error during command
decoding*
1
311146 FM_Z_IC_DECODE IC/Z axis: error during command
decoding*
1
311147 FM_D_IC_DECODE IC/D axis: error during command
decoding*
1
311148 FM_X_KLEMMT_REF X axis: jamming during reference run* 1
311149 FM_Y_KLEMMT_REF Y axis: jamming during reference run* 1
311150 FM_S_KLEMMT_REF S axis: jamming during reference run* 1
311151 FM_Z_SP_KLEMMT_REF SP/Z axis: jamming during reference
run*
1
311152 FM_D_KLEMMT_REF SP/D axis: jamming during reference
run*
1
311153 FM_Z_IC_KLEMMT_REF IC/Z axis: jamming during reference 1
GEM for SIPLACE V5.01
©Siemens AG, all rights reserved page 199 of 252
CEID Name Description
run*
311154 FM_X_ENDSCHALTER X axis: limit switch actuated* 1
311155 FM_Y_ENDSCHALTER Y axis: limit switch actuated* 1
311156 FM_S_ENDSCHALTER S axis: limit switch actuated* 1
311157 FM_Z_SP_ENDSCHALTER SP/Z axis: limit switch actuated* 1
311158 FM_D_ENDSCHALTER SP/D axis: limit switch actuated* 1
311159 FM_Z_IC_ENDSCHALTER IC/Z axis: limit switch actuated* 1
311160 FM_D_IC_ENDSCHALTER IC/D axis: limit switch actuated* 1
311161 FM_X_SERVO_STOERUNG X axis: servo card reports fault* 1
311162 FM_Y_SERVO_STOERUNG Y axis: servo card reports fault* 1
311163 FM_S_SERVO_STOERUNG S axis: servo card reports fault* 1
311164 FM_Z_SP_SERVO_STOERUNG SP/Z axis: servo card reports fault* 1
311165 FM_D_SERVO_STOERUNG SP/D axis: servo card reports fault* 1
311166 FM_Z_IC_SERVO_STOERUNG IC/Z axis: servo card reports fault* 1
311167 FM_D_IC_SERVO_STOERUNG IC/D axis: servo card reports fault* 1
311168 FM_X_SERVO_STROMBEGR X axis: I rms current limiting* 1
311169 FM_Y_SERVO_STROMBEGR Y axis: I rms current limiting* 1
311170 FM_S_SERVO_STROMBEGR S axis: I rms current limiting* 1
311171 FM_Z_SP_SERVO_STROMBEG
R
SP/Z axis: I rms current limiting* 1
311172 FM_D_SERVO_STROMBEGR SP/D axis: I rms current limiting* 1
311173 FM_Z_IC_SERVO_STROMBEG
R
IC/Z axis: I rms current limiting* 1
311174 FM_D_IC_SERVO_STROMBEG
R
IC/D axis: I rms current limiting* 1
311175 FM_X_SELBSTTEST X axis: Self-test unsuccessful* 1
311176 FM_Y_SELBSTTEST Y axis: Self-test unsuccessful* 1
311177 FM_S_SELBSTTEST S axis: Self-test unsuccessful* 1
311178 FM_Z_SP_SELBSTTEST SP/Z axis: Self-test unsuccessful* 1
311179 FM_D_SELBSTTEST SP/D axis: Self-test unsuccessful* 1
311180 FM_Z_IC_SELBSTTEST IC/Z axis: Self-test unsuccessful* 1
311181 FM_D_IC_SELBSTTEST IC/D axis: Self-test unsuccessful* 1
311182 FM_X_DA_TEST X axis: testing DA outputs faulty* 1
311183 FM_Y_DA_TEST Y axis: testing DA outputs faulty* 1
311184 FM_S_DA_TEST S axis: testing DA outputs faulty* 1
311185 FM_Z_SP_DA_TEST SP/Z axis: testing DA outputs faulty* 1
311186 FM_D_DA_TEST SP/D axis: testing DA outputs faulty* 1
311187 FM_Z_IC_DA_TEST IC/Z axis: testing DA outputs faulty* 1
GEM for SIPLACE V5.01
Page 200 of 252 ©Siemens AG, all rights reserved
CEID Name Description
311188 FM_D_IC_DA_TEST IC/D axis: testing DA outputs faulty* 1
311189 FM_X_ZAEHLSPUREN_TEST X axis: testing counting tracks faulty* 1
311190 FM_Y_ZAEHLSPUREN_TEST Y axis: testing counting tracks faulty* 1
311191 FM_S_ZAEHLSPUREN_TEST S axis: testing counting tracks faulty* 1
311192 FM_Z_SP_ZAEHLSPUREN_TES
T
SP/Z axis: testing counting tracks
faulty*
1
311193 FM_D_ZAEHLSPUREN_TEST SP/D axis: testing counting tracks
faulty*
1
311194 FM_Z_IC_ZAEHLSPUREN_TES
T
IC/Z axis: testing counting tracks
faulty*
1
311195 FM_D_IC_ZAEHLSPUREN_TES
T
IC/D axis: testing counting tracks
faulty*
1
311196 FM_X_DA_ABGLEICH_TEST X axis: DA calibration faulty* 1
311197 FM_Y_DA_ABGLEICH_TEST Y axis: DA calibration faulty* 1
311198 FM_S_DA_ABGLEICH_TEST S axis: DA calibration faulty* 1
311199 FM_Z_SP_DA_ABGLEICH_TES
T
SP/Z axis: DA calibration faulty* 1
311200 FM_D_DA_ABGLEICH_TEST SP/D axis: DA calibration faulty* 1
311201 FM_D_IC_DA_ABGLEICH_TEST IC/D axis: DA calibration faulty* 1
311202 FM_Z_IC_DA_ABGLEICH_TEST IC/Z axis: DA calibration faulty* 1
311203 FM_X_UNDEFINIERT X axis: error number undefined* 1
311204 FM_Y_UNDEFINIERT Y axis: error number undefined* 1
311205 FM_S_UNDEFINIERT S axis: error number undefined* 1
311206 FM_Z_SP_UNDEFINIERT SP/Z axis: error number undefined* 1
311207 FM_D_UNDEFINIERT SP/D axis: error number undefined* 1
311208 FM_Z_IC_UNDEFINIERT IC/Z axis: error number undefined* 1
311209 FM_D_IC_UNDEFINIERT IC/D axis: error number undefined* 1
311210 FM_AX_STD_DATEN Axis error: standard data not read* 1
311211 FM_AX_MA_DATEN Axis error: MA data not read* 1
311212 FM_AX_STD_FILE Axis error: Standard data file not
found*
1
311213 FM_AX_MA_FILE Axis error: standard data file not
found*
1
311214 FM_AX_KMD_ENDE Axis error: no end flag before new
command*
1
311215 FM_AX_KMD_DAIN Axis error: no DAIN flag before new
command*
1
311216 FM_AX_KMD_ENDE_SET Axis error: Command end, but bit set* 1
311217 FM_AX_KMD_DAIN_SET Axis error: Command DAIN, but bit
set*
1
311218 FM_AX_ANFRAGE_ID Axis error: no ID for MBX inquiry* 1
